TECHNICAL SPECIFICATIONS

tecHnIcAL sPecIFIcAtIons
Power supply:
Maximum current consumption:
Power transformer for µAc and digital
inputs:
operating range:
Accuracy of measurement (excluding
probe):
Resolution:
operating conditions:
storage conditions:
Analogue inputs:
Digital inputs:
Analogue outputs:
Digital outputs:
Max. ntc probe cable length:
Max. digital input cable length:
Max. power output cable length:
Max. fan control output cable length:
type of action of relay and triac:
Maximum number of relay switchings:
Insulation between the relay and low
voltage parts:
Insulation between the relay and the
front panel:
Insulation between the two relays:
PtI of materials used for insulation:
Category of resistance to heat and fire:
Front panel index of protection:
environmental pollution:
Period of electrical stress across
insulating parts:
software class and structure:
Immunity against voltage surges:
Interfaces:
Installation:
Method of connection:
Max. no. of connector insertions/removals:
Page 0 - IOM / @DNOVA-µAC-0907-E
24Vac ±15% 50/60Hz
200mA with internal 800mA T fuse (slow-blow)
10VA
Temperature probes -30÷70°C Humidity probe 0÷100% r.H.
±0.5°C NTC probes / ±0.005V 0.5% f.s. 0÷1Vdc probe / ±0.02mA 1% f.s.
4÷20mA probe
0.1°C
-10T54 (-10÷54°C) with 20÷80% r.H. non-condensing
-10T70 (-10÷70°C) with 0÷80% r.H. non-condensing
B1-B2-B4, for 3 NTC Carel temperature probes (10K. at 25°C) B3, 1 0÷1Vdc/
4÷20mA input for humidity or pressure probe (selected using rear pin strip) +V,
Probe power output 14Vdc 30mA max
ID1-ID10, 10 inputs not optically isolated from power supply potential G0
powered at 24Vac current consumed by each input 6.5mA at 24Vac. The alarms
are active when the corresponding input is open (not powered). Input ID1,
for Remote ON/OFF, switches on the machine when powered. Input ID7, for
Cooling/heating, enables heating operation when powered.
Y1, 0÷10Vdc output not optically isolated from power supply potential G0,
maximum load 10mA 1K. Y2, 1 phase-cut output for Carel MCHRTF*0A0
regulator, impulsive at mains frequency, configured by user parameters for
pulse width modulation (PWM) or position, with loadless voltage of 4.8V ±10%
on minimum load of 1K.
oUt1-5, 5 SSR 24Vac 1A (optically isolated in three groups from G-Go) with
minimum current of 20mA. In addition, the 3 groups C1/2-OUT1-OUT2, C3/4-
OUT3-OUT4, C5-OUT5 are insulated from each other and this insulation is
functional (voltage < 50V). GND and G0 are connected internally. oUt6-c6,
1 220Vac relay, switching contact, contacts protected by 250Vac varistors
oUt7-c7, 1 220Vac relay, normally open contact, contacts protected by 250Vac
varistors Max. relay current 2A (resistive and inductive) according to VDE 0631
for 100,000 switchings at 85°C
50m
100m
100m
50m
1C (micro-switching)
100,000
reinforced
reinforced
primary
250V
Category D (self-extinguishing UL94-V0)
IP55
normal
long
A
Category II
Pin-strip for optically isolated RS485 serial board MAC2SER000 (optional)
Pin-strip for clock board MAC2CLK000 (optional) Connector for programming
key Connector for updating microprocessor software
Panel mounting, see chapter on Dimensions.
Connections are made using the four rear connectors. For the connections use
the connectors supplied or Carel code MAC2CON001:
Molex® code for the female connectors
39-01-2080
39-01-2120
39-01-2180
Molex® code for the connector contact cross-sec. allowed for cables
39-00-0077
39-00-0038 (Carel code 5931189AXX)
39-00-0046
For crimping use the relative Molex® tool 69008-0724
25 cycles
Way
8
12
18
AWG16 (1.25mm )
2
AWG18-24 (0.90 - 0.35mm
2
AWG22-28 (0.22 - 0.06 mm
)
)
2
