MOD-6107/ MOD-6108 ELECTRIC ADJUSTABLE BED
Step 2:
Remove base from plastic bag and box. Unfold the bed base and keep the bottom of the base facing
upward.
Step 3:
Move the iron pad down and install the six legs firmly into the base of the frame. The legs screw into the threaded
holes on each corner of the adjustable base frame (See Figure below).
-Pls tighten them fully but do not over tighten.
Figure 1
Step 4:
Extend the input power cord (labeled "b" in the photograph below) and plug it into the transformer power supply
(labeled "c" in the photograph below). Connect the transformer power supply to the control box. The control box
is the black box attached to the bottom of the bed.
Figure 2
Customer Service 908-368-1025︱www.modway.com
Page 4 of 6
