- Page 1 SILVERLINE FI INSTALLATION AND USER MANUAL for your heat pump Models 70 / 90 / 120 / 150 / 200 www.poolstar.fr...
- Page 2 Warning This heat pump contains a flammable refrigerant R32. Any intervention on the refrigerant circuit is prohibited without a valid authorization. Before working on the refrigerant circuit, the following precautions are necessary for safe work. 1. Work procedure The work must be carried out according to a controlled procedure, in order to minimize the risk of presence of flammable gases or vapors during the execution of the works.
- Page 3 Thank you Dear Customer, Thank you for your purchase and for your confidence in our products. These are the result of many years of research in the field of design and production of heat pumps for swimming pools. Our aim is to provide you with an exceptional high performance quality product.
- Page 4 PLEASE READ CAREFULLY. These installation instructions are an integral part of the product. They must be given to the installer and retained by the user. If the manual is lost, please consult the website: www.poolex.fr The instructions and recommendations contained in this manual should be read carefully and understood since they provide valuable information concerning the heat pump’s safe handling and operation.
-
Page 5: Table Of Contents
Contents 1. General ......................................6 General Terms of Delivery ................................. 6 Safety instructions..................................6 Water treatment ..................................7 2. Description ...................................... 8 Package contents ..................................8 General characteristics ................................8 Technical specifications ................................9 Unit dimensions ..................................10 Exploded view ....................................11 3. -
Page 6: General
1. General General Terms of Delivery All equipment, even if shipped ‘free of carriage and packing’, is dispatched at the consignee’s own risk The person responsible for receiving the equipment must carry out a visual inspection to identify any dam- age to the heat pump during transport (refrigerant system, body panels, electrical control box, frame). -
Page 7: Water Treatment
1. General During use To avoid serious injuries, never touch the fan when it is operating. Keep the heat pump out of the reach of children to avoid serious injuries caused by the heat exchanger’s blades. Never start the equipment if there is no water in the pool or if the circulating pump is stopped. Check the water flow rate every month and clean the filter if necessary. -
Page 8: Description
2. Description Package contents Heat pump Poolex Silverline FI 2 hydraulic inlet/outlet connectors (50mm diameter) Extension cable for remote control panel This installation and user manual Condensation draining kit Winter storage cover 4 anti-vibration pads (fastenings not supplied) General characteristics A Poolex heat pump has the following features: CE certification and complies with the RoHS European directive. -
Page 9: Technical Specifications
2. Description 2.3 Technical specifications Poolex Silverline FI Test conditions Heating power (kW) 6.8~1.94 9.2~2.23 11.3~2.28 14.5~2.25 19.2~2.59 Power in mode Silence (kW) 3.31~1.54 4.75~2.23 5.77~2.08 7.31~2.25 10.47~2.59 26°C Consumption (kW) 1.05~0.15 1.46~0.16 1.86~0.13 2.43~0.14 3.14~0.16 Water 26°C Consumption in Silence (kW) 0.36~0.12 0.47~0.16 0.61~0.13... -
Page 10: Unit Dimensions
2. Description 2.4 Unit dimensions Dimensions en mm Silverline FI 70 / 90 / 120 1143 1107... -
Page 11: Exploded View
2. Description 2.5 Exploded view 1. Top panel 13. Front panel 2. Logic board box 14. Fan blade 3. Back panel 15. Fan motor 4. Pressure gauge 16. Fan support 5. Water Flow Switch 17. Electrical terminal block 6. Heat exchanger 18. -
Page 12: Installation
3. Installation WARNING: Installation must be carried out by a qualified engineer. This section is provided for information purposes only and must be checked and adapted if necessary according to the actual installation conditions. Pre-requirements Equipment necessary for the installation of your heat pump: Power supply cable suitable for the unit’s power requirements. -
Page 13: Installation Layout
3. Installation 3.3 Installation layout Heat pump Automated treatment system 4-way valve (salt chlorinator, metering pump) Valve 1 Valve 5 Valve 2 Water outlet Water intake Elevating studs Valve 4 Condensation Circulating Filtration draining pump FROM THE POOL TOWARDS THE POOL Valves 1, 2 and 3: Bypass valves Valves 4 and 5: Regulating valves (Recommended for facilitating adjustments close to the machine) -
Page 14: Hydraulic Connection
3. Installation WARNING: Installation must be carried out by a qualified engineer. This section is provided for information purposes only and must be checked and adapted if necessary according to the actual installation conditions. Hydraulic connection By-Pass assembly Open valve The heat pump must be connected to the pool by Half-open valve means of a By-Pass assembly. - Page 15 3. Installation By-Pass assembly for one heat pump TOWARDS THE POOL Automated treatment system POOL Filtration + Pump FROM THE POOL Half-open valve Open valve By-Pass assembly for more than one heat pump TOWARDS THE POOL Automated treatment system POOL Filtration + Pump FROM THE POOL Half-open valve...
-
Page 16: Electrical Installation
3. Installation WARNING: Installation must be carried out by a qualified engineer. This section is provided for information purposes only and must be checked and adapted if necessary according to the actual installation conditions. Electrical installation To function safely and maintain the integrity of your electrical system, the unit must be connected to a general electricity supply in accordance with the following regulations: Upstream, the general electricity supply must be protected by a 30 mA differential switch. -
Page 17: Electrical Connection
3. Installation Electrical connection WARNING: The heat pump’s power supply MUST be disconnected before any operation. VPlease comply with the following instructions to electrically connect the heat pump. Step 1: Detach the electrical side panel with a screwdriver to access the electrical terminal block. Step 2: Insert the cable into the heat pump unit by passing it through the opening provided for that purpose. -
Page 18: Use
4. Use Wired remote control ROOM VALUE TEMP AUTO Control box displays Before starting, ensure that the filtration pump is working and that water is circulating through the heat pump. Prior to setting your required temperature, you must first select an operating mode for your heat pump: Cooling mode Speed compressor Full Inverter... -
Page 19: Remote Control Display
4. Use ROOM VALUE TEMP AUTO Operating mode selector Push on to change the operating mode. The different modes appear in the following order: Heating mode Full Inverter Cooling Mode Full Inverter Heating mode Boost Cooling mode Boost Heating mode Eco silence Cooling mode Eco silence... -
Page 20: Current Time Setting
4. Use ROOM VALUE TEMP Setting the clock ROOM VALUE ROOM VALUE ROOM VALUE TEMP AUTO TEMP TEMP ROOM VALUE ROOM VALUE ROOM VALUE TEMP AUTO AUTO TEMP AUTO TEMP Step 1 : press 5s to to enter current time setting. ROOM VALUE TEMP... -
Page 21: Timer On/Off Setting
4. Use Programming Start/Stop Bon à savoir ROOM VALUE TEMP This function is for programming the Start/Stop timing. You can programme up to 3 different Start/Stop timings. Setting ROOM VALUE ROOM VALUE ROOM VALUE TEMP TEMP TEMP is as follows: AUTO AUTO AUTO... -
Page 22: Status Values
4. Use System parameter query 4.11 Bon à savoir WARNING : This operation is used to assist servicing and future repairs. The default settings should only be modified by an experienced professional person. WARNING : Any change to the reserved settings will automatically void the warranty. ROOM VALUE TEMP... - Page 23 4. Use Temperature auxiliary heater start 2~15°C 5°C Adjustable Temperature difference between inlet and outlet protection 2~60°C 10°C Adjustable Bottom plate heater temperature start -9~10°C 0°C Adjustable High fan speed Adjustable Mid fan speed 300~1500 Adjustable Low fan speed Adjustable Reserve Reserve Reserve...
-
Page 24: Operation
5. Operation Operation Conditions of use For the heat pump to operate normally, the ambient air temperature must be between -7°C and 43°C. Recommendations prior to start-up Before activating the heat pump, please: Check that the unit is firmly secured and stable. Check that the gauge indicates a pressure greater than 80 psi. -
Page 25: Using The Pressure Gauge
5. Operation Using the pressure gauge The gauge is for monitoring the pressure of the refrigerant contained in the heat pump. The values it indicates can vary considerably, depending on the climate, temperature and atmospheric pressure. When the heat pump is in operation: The gauge’s needle indicates the refrigerant pressure. -
Page 26: Maintenance And Servicing
6. Maintenance and servicing Maintenance and servicing WARNING: Before undertaking maintenance work on the unit, ensure that you have disconnected the electrical power supply. Cleaning The heat pump’s casing must be cleaned with a damp cloth. The use of detergents or other household products could damage the surface of the casing and affect its properties. -
Page 27: Repairs
7. Repairs WARNING: Under normal conditions, a suitable heat pump can heat the water in a swimming pool by 1°C to 2°C per day. It is therefore quite normal to not feel any temperature difference in the system when the heat pump is working. A heated pool must be covered to avoid any loss of heat. -
Page 28: List Of Faults
7. Repairs List of faults Code Fault Possible causes Action Check your water circuit operation and the opening of the By-Pass Insufficient water in heat exchanger valves Flow sensor malfunction Sensor disconnected or defective Reconnect or replace sensor Protection activated when the ambient temperature is too low and Antifreeze protection No intervention is necessary the unit is on standby... -
Page 29: Wiring Diagrams
7. Repairs Wiring diagrams Power supply Water pump 220V Buttom plate heater low pressure CN13 switch Water flow switch High pressure CN11 switch CN20 CN19 CN18 CN17 CN16 CN15 white blue Suction Outlet Inlet Coil Ambient Discharge temp. Water water temp. -
Page 30: Recycling
8. Recycling Recycling the heat pump Your heat pump has reached the end of its life and you wish to dispose of it or to replace it. Do not throw it in the rubbish bin. A heat pump must be disposed of separately with a view to its reuse, recycling or upgrading. It contains substances that are potentially hazardous to the environment but which will be eliminated or neutralised by recycling. -
Page 31: Warranty
Poolstar company. The guaranteed parts shall be replaced or repaired at Poolstar’s discretion. Defective parts must be returned to our workshops to be covered during the warranty period. The warranty does not cover labour costs or unauthorised replacements. - Page 32 A S SI ST AN C E T E CH N IQ UE www.poolex.fr 01-2020 www.poolstar.fr...
