DEMO MANUAL DC1948A
parts list
ITEM QTY REFERENCE
Required Circuit Components
1
2
C1, CIN2
2
1
C2
3
1
C4
4
1
R1
5
1
R2
6
1
R4
7
1
R5
8
1
R6
9
1
R7
10
1
R8
11
1
R9
12
1
R11
13
1
R12, R14
14
1
U1
Additional Demo Board Circuit Components
1
1
CIN1
2
0
C3 (OPT)
3
0
R10, R13, R15 (OPT) RES, 0603
Hardware: For Demo Board Only
1
8
E1, E2, E3, E4, E6,
E7, E8, E9
2
1
JP1
3
1
JP2
4
1
JP3
5
1
JP4
6
4
XJP1, XJP2, XJP3,
XJP4
4
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Downloaded from
Downloaded from
Downloaded from
Downloaded from
PART DESCRIPTION
CAP, X7R 4.7µF 50V 10% 1206
CAP, X7R 0.1µF 16V 10% 0603
CAP, X7R 1µF 10V 10% 0603
RES, CHIP 10k 0.1W 1% 0805
RES, CHIP 49.9k 0.1W 1% 0805
RES, CHIP 2k 0.06W 1% 0603
RES, CHIP 24.9k 0.06W 1% 0603
RES, CHIP 49.9k 0.06W 1% 0603
RES, CHIP 100k 0.06W 1% 0603
RES, CHIP 243k 0.06W 1% 0603
RES, CHIP 301k 0.06W 1% 0603
RES, CHIP 1k 0.06W 1% 0603
RES, CHIP 0Ω 0.25W 5A 0603
IC, NEGATIVE LINEAR REG DFN(10) (DD) 3mm × 3mm
CAP, ALUM 10µF 50V 10%
CAP, 1206
TURRET, TESTPOINT
HEADERS, DBL ROW 2 × 2 2mm CTRS
HEADERS, DBL ROW 2 × 6 2mm CTRS
HEADERS, DBL ROW 2 × 3 2mm CTRS
HEADERS, 2mm CTRS
SHUNT, 2mm CTRS
MANUFACTURER/PART NUMBER
TDK C3216X7R1H475KT
AVX 0603YC104KAT2A
TAIYO YUDEN LMK107BJ105KA
VISHAY CRCW080510K0FKTA
VISHAY CRCW080549K9FKTA
VISHAY CRCW06032K00FKEA
VISHAY CRCW060324K9FKEA
VISHAY CRCW060349K9FKEA
VISHAY CRCW0603100KFKEA
VISHAY CRCW0603243KFKEA
VISHAY CRCW0603301KFKEA
VISHAY CRCW06031K00FKEA
VISHAY CRCW06030000Z0EA
LINEAR TECHNOLOGY CORPORATION LT3090EDD
SUNCON 50CE10BSS
MILL MAX 2501-2-00-80-00-00-07-0
SAMTEC TMM-102-02-L-D
SAMTEC TMM-106-02-L-D
SAMTEC TMM-103-02-L-D
SAMTEC ASP-157349-01
SAMTEC 2SN-BK-G
dc1948af
