Specifications - Uniden MC 1010 Operating Manual

Mc 1010 vhf marine radio
Hide thumbs

Advertisement

Color profile: Disabled
Composite
Default screen
General
Channels:
Controls:
Status Indicators:
Channel Display:
Selector Switch:
Buttons:
Connectors:
Size:
Weight:
Supply Voltage:
Standard Accessories:
Antenna Impedance:
Microphone:
Speaker:
Operating Temperature Range:
Shock and Vibration:
FCC Approvals:
Transmitter
Power Output:
Power Requirement:
Modulation:
Hum and Noise Signal-to-Noise:
Audio Distortion:
Spurious Suppression:
Output Power Stabilization:
Frequency Range:
Frequency Stability:
Receiver
Frequency Range:
Sensitivity:
Circuit:
Squelch Sensitivity:
Spurious Response:
Adjacent Channel Selectivity:
Audio Output Power:
Power Requirement:
IF Frequencies:
C:...MC 1010.vp
Thu Jan 28 14:42:58 1999

Specifications

Transmit: 54
Receive: 77 Marine/10 Weather
On-Off/Volume, Squelch
TX LED (transmit), SCAN, TRI, U, I, C, HI, LO,
MEM, and WX symbol on LCD Panel
LCD (Dual 7 segment)
Channel Selector switch
WX, 16/9, MEM, H/L, and STEP
Antenna, remote speaker, and DC power
2 1/5"H x 6 2/5"W x 8"L
2.4 lbs
13.8V DC negative ground
Mounting bracket and hardware, DC power cord,
microphone hanger, spare fuse
50 nominal
Rugged 1k condenser mic element with
coiled cord
1.82 inch, 8
– 20°C to +50°C (– 4°F to +122°F)
Meets or exceeds EIA standards, RS152B
and RS204C
Type accepted under part 80 of the Rules;
meets Great Lakes Agreement and party
boat requirements
1 watt or 25 watt (switch selectable)
Not rated on LO;
25 watts output: 4.5A@13.8V DC
FM 5 kHz deviation (FCC designator F3E)
42 dB@300 HZ, 3kHz (nominal)
Less than 3% with 3 kHz deviation with 1000 Hz
modulating frequency (nominal)
– 56 dB @ 1 watt, – 65 dB @ 25 watts
Built-in automatic level control (ALC)
156 to 158 mHz
1.58 kHz @ – 20°C to +50°C
156 to 163 MHz
0.25 V for 12 dB SINAD
0.35 V for 20 dB S/N
Dual Conversion Super Heterodyne PLL
0.5 v Threshold
60 dB
60 dB @ 25 kHz
3.0 watts (10% Distortion)
230 mA @ 13.8V DC squelched
0.7A @ 13.8V DC at maximum audio output
1st - 16.9 mHz
2nd - 455 kHz
15
