H-1250
Foot-operated
Impulse sealer
1.
Read all instructions before use and save these
instruction for later use.
2. Follow all warnings and instructions marked on
the product.
3. Unplug this product from the power source before
cleaning and/or changing any parts.
4. Do not rest anything on the power cord. Do not
place the machine where the power cord may be
stepped on or pulled.
5. Always keep out of reach of children and pets.
6. This sealer should only be in use with an operator in
attendance.
7.
Never insert clothing, hand or fingers between the
sealing jaws of sealers or into the feed opening of
continuous sealers.
8. Never touch the heating elements with bare hands
while the sealer is plugged into a power source, in
operation, or just finished operation. It is HOT.
9. Be sure to check for worn parts before starting
operation.
Page 1 of 3
1-800-295-5510
uline.com
Safety
WaRNING! Never connect the sealer's
power cord to outlet during assembly.
10. Do not operate with a damaged power cord or plug.
11. Always keep the unit clean. Do not use water.
Silicone spray may be used to clean the unit. Be
sure the unit is unplugged from the power source
before cleaning.
12. When changing blade (for sealer with cutter), be
careful of the sharp edge.
13. When changing the Teflon adhesive, be sure that
the entire surface under the heating element is
covered with Teflon adhesive. Bend down the excess
Teflon adhesive on both ends. This will prevent the
heating element from breaking and the machine
from grounding.
14. When replacing fuse, be sure the exact voltage and
ampere is used.
15. Be sure to keep a record of your model number.
Specify this number when ordering
16. When replacing any parts, be sure to mark down the
exact locations of the connections, and the orders
of the different pieces.
0714 IH-1250

Advertisement

loading
Need help?

Need help?

Do you have a question about the H-1250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for U-Line H-1250

  • Page 1 H-1250 1-800-295-5510 uline.com Foot-operated Impulse sealer WaRNING! Never connect the sealer’s power cord to outlet during assembly. Safety Read all instructions before use and save these 10. Do not operate with a damaged power cord or plug. instruction for later use.
  • Page 2 aSSeMBly Position the pedestal on the floor standing upright. 2. Mount the complete sealer assembly to the top of the pedestal and attach with four screws. 3. Position spring under the sealer’s upper level. The Control Set pull-rod goes through the spring and is fastened to the upper level.
  • Page 3 tROUBleSHOOtING Most sealers work on the principle that when the sealing Sealing is followed by cooling (the amount of time arm is pressed down, it activates a microswitch which needed for the seal to set). This affects the beauty of allows electric current to pass through the heating the seal.
