Item # 1001 073 619
Model # FRS50421U-ST-1
USE AND CARE GUIDE
FRANKLIN ESTATES KD 5-PIECE DINING SET-CHAIR
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY Franklin Estates KD
Summary of Contents for HAMPTON BAY Franklin Estates KD
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this chair. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Hardware Included ..............3 Save These Instructions ............2 Package Contents..............4 Read All Instructions Before Use ..........2 Assembly................ -
Page 3: Warranty
Warranty 2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Backrest Right arm Left arm Seat Seat cushion Lumbar pillow... -
Page 5: Assembly
Assembly Connecting the seat to the backrest Place the backrest (A) on a soft surface. Connect the seat (D) to the backrest (A) using M6x30 combination bolts (AA). Do not fully tighten all the bolts at this step. NOTE : Loosely tighten all the bolts using the hex wrench (CC). HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance. - Page 6 Assembly (continued) Connecting the left arm to the backrest Attach the left arm (C) to the backrest (A) by inserting the tube on the left arm (C) into the tube on the backrest (A).
- Page 7 Assembly (continued) Connecting the left arm to the seat and the backrest Turn over the chair as the image shows and attach the left arm (C) to the seat (D) and the backrest (A) using M6x25 combination bolts (BB). Do not fully tighten all the bolts at this step. NOTE : Loosely tighten all the bolts using the hex wrench (CC).
- Page 8 Assembly (continued) Connecting the right arm to the backrest Repeat step 2 to attach the right arm (B) to the backrest (A).
- Page 9 Assembly (continued) Connecting the right arm to the seat and the backrest Turn the chair upside down. Repeat step 3 to attach the right arm (B) to the seat (D) and the backrest (A) using M6x25 combination bolts (BB). Do not fully tighten all the bolts at this step. NOTE : Loosely tighten all the bolts using the hex wrench (CC).
-
Page 10: Care And Cleaning
Assembly (continued) Tightening the bolts Once all of the bolts are in place, fully tighten the bolts. Turn the chair right side up. Ensure all connections are secure before use. Place the seat cushion (E) and the lumbar pillow (F) to complete the assembly of the chair. Care and Cleaning For best results, clean the chair with a damp cloth and dry thoroughly. - Page 11 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
