Item # 1001 748 105
Model # FRS71046-ST
USE AND CARE GUIDE
PACIFIC 7PC DINING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive continually to create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY PACIFIC FRS71046-ST
Summary of Contents for HAMPTON BAY PACIFIC FRS71046-ST
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive continually to create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents ............2 Pre-A ssembly ............... 3 Planning Assembly ..............3 Important Safety Instructions ........2 Hardware Included ..............3 Save These Instructions ............2 Chair Package Contents............4 Read All Instructions Before Use ..........2 Table Package Contents............ -
Page 3: Warranty
Warranty 3 YEAR FRAME AND FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchaser for three years, and the fabric to have three years limited warranty. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Chair Package Contents
Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Chair Back Left Arm Right Arm Chair Seat Back Cushion Seat Cushion... - Page 5 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Umbrella Ring Table Top Leg Connector Table Leg HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 6: Chair Assembly
Chair Assembly Connecting the Chair Seat to the Right Arm Place the right arm (C) on a soft surface. Attach the chair seat (D) to the right arm (C) using M6x30 combination bolts (BB). Do not tighten all bolts at this step. NOTE: Loosely tighten all the bolts using hex wrench (CC). - Page 7 Chair Assembly (continued) Connecting the Chair Back to the Left Arm and the Right Arm Turn the chair right side up. Attach the chair back (A) to the left arm (B) and the right arm (C) using M6x20 combination bolts (AA). Do not tighten all bolts at this step.
- Page 8 Table Assembly Attaching the Leg Connector to the Table Legs Attach the leg connector (I) to the table legs (J) using M6x20 combination bolts (AA). Do not tighten all bolts at this step. NOTE: Loosely tighten all the bolts using hex wrench (CC). Attaching the Table Legs to the Table Top Place the table top (H) upside down on a soft surface.
-
Page 9: Care And Cleaning
Table Assembly (continued) Tightening the Bolts and Placing the Umbrella Ring Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (CC). Turn the table right side up. Put the umbrella ring (G) to the table top. Ensure all connections are secure before use. - Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
