Item # 1001 073 619
Model # FRS50421U-ST-1
USE AND CARE GUIDE
FRANKLIN ESTATES
KD 5-PIECE DINING SET-TABLE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this table. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS50421U-ST-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for HAMPTON BAY FRS50421U-ST-1

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this table. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Hardware Included ..............3 Save These Instructions ............2 ..............Package Contents Read All Instructions Before Use ..........2 .......
  • Page 3: Warranty

    Warranty 2 YEAR FRAME WARRANTY WHAT IS COVERED We warrant the frame to be free of manufacturing defects to the original purchas for two years. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover s warranty.
  • Page 4: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table top Table leg 1 Table leg 2 Metal sheet Table ring...
  • Page 5: Assembly

    Assembly Connecting the table leg 1 to the table top Place the table top (A) upside down on a soft surface. Attach the table leg 1 (B) to the table top (A) using M6x20 combination bolts (AA). NOTE : Loosely tighten all the bolts using the hex wrench (BB). HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 6 l (continued) Assembly Connecting the table leg 2 to the table top Attach the table leg 2 (C) to the table top (A) using M6x20 combination bolts (AA). Connect the table legs 2 (C) to the table leg 1 (B) using M6x20 combination bolts (AA). Do not fully tighten all the bolts at this step.
  • Page 7 l (continued) Assembly Connecting the metal sheet to the table legs Attach the metal sheet (D) to the table legs (B & C) using M6x20 combination bolts (AA). Do not fully tighten all the bolts at this step. NOTE : Loosely tighten all the bolts using the hex wrench (BB). HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 8: Care And Cleaning

    Assembly (continued) Attaching the table ring Once all of the bolts are in place, fully tighten the bolts. Turn the table right side up and cover the center hole with the table ring (E). Ensure all connections are secure before use. Care and Cleaning For best results, clean the table with a damp cloth and dry thoroughly.
  • Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
