BEACON PARK STEEL 4-PIECE DEEP SEATING SET
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this seating set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
1-855-HD-HAMPTON
HOMEDEPOT.CA
Thank you for choosing Hampton Bay!
THANK YOU
Item # 1001 074 528
1001 189 700
1001 186 712
Model
#
FRS80812C-ST-1
FRS80812C-ST-1O
FRS80812C-ST-1B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BEACON PARK FRS80812C-ST-1 and is the answer not in the manual?

Questions and answers

Related Manuals for HAMPTON BAY BEACON PARK FRS80812C-ST-1

Summary of Contents for HAMPTON BAY BEACON PARK FRS80812C-ST-1

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this seating set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Hardware Included ..............Save These Instructions ............2 Club Chair Package Contents ..........Read All Instructions Before Use ..........2 Loveseat Package Contents ..........

  • Page 3: Warranty

    Warranty 2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center.

  • Page 4: Club Chair Package Contents

    Pre-Assembly (continued) CLUB CHAIR PACKAGE CONTENTS Part Description Quantity Right arm Left arm Club chair seat Club chair back Back cushion Seat cushion...

  • Page 5: Loveseat Package Contents

    Pre-Assembly (continued) LOVESEAT PACKAGE CONTENTS Part Description Quantity Right arm Left arm Back cushion Seat cushion Loveseat seat Loveseat back HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance...

  • Page 6: Coffee Table Package Contents

    Pre-Assembly (continued) COFFEE TABLE PACKAGE CONTENTS Part Description Quantity Table top Table leg Leg connector...

  • Page 7: Club Chair Assembly

    Club Chair Assembly ATTACHING THE CLUB CHAIR SEAT TO THE RIGHT ARM Place the right arm (A) on a soft surface. Align the holes on the right panel of the club chair seat (C) to the holes on the front of the right arm (A), and secure by M6x20 combination bolts (AA).
  • Page 8 Club Chair Assembly (continued) ATTACHING THE CLUB CHAIR BACK TO THE RIGHT ARM AND THE CLUB CHAIR SEAT Attach the club chair back (D) to the right arm (A) and the club chair seat (C) using an M6x20 combination bolt (AA) and M6X50 combination bolts (CC).
  • Page 9 Club Chair Assembly (continued) CONNECTING THE LEFT ARM TO THE CLUB CHAIR SEAT AND THE CLUB CHAIR BACK Connect the left arm (B) to the club chair seat (C) and the club chair back (D) using M6x20 combination bolts (AA). Do not fully tighten all the bolts at this step.
  • Page 10 Club Chair Assembly (continued) ATTACHING THE ARMS TO THE CLUB CHAIR BACK Turn the club chair right side up. Connect the back of the right and the left arm (A & B) to the club chair back (D) by using M6x50 combination bolts (CC). Do not tighten all the bolts at this step.
  • Page 11 Club Chair Assembly (continued) CHECKING THE CLUB CHAIR Once all of the bolts are in place, fully tighten the bolts. Ensure all connections are secure before use. Place the seat cushion (F) and the back cushion (E) to finish the assembly of the club chair. HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON...

  • Page 12: Loveseat Assembly

    Loveseat Assembly CONNECTING THE RIGHT ARM TO THE LOVESEAT SEAT Place the right arm (A) on the soft surface. Align the holes on the right panel of the loveseat seat (G) to the holes on the front of the right arm (A), and secure by M6x20 combination bolts (AA) using the hex wrench (DD).
  • Page 13 Loveseat Assembly (continued) ATTACHING THE LOVESEAT BACK TO THE RIGHT ARM AND THE LOVESEAT SEAT Attach the loveseat back (H) to the right arm (A) and the loveseat seat (G) using an M6x20 combination bolt (AA) and M6x50 combination bolts (CC). Do not fully tighten all the bolts at this step.
  • Page 14 Loveseat Assembly (continued) CONNECTING THE LEFT ARM TO THE LOVESEAT SEAT AND THE LOVESEAT BACK Connect the left arm (B) to the loveseat seat (G) and the loveseat back (H) using M6x20 combination bolts (AA). Do not fully tighten all bolts at this step.
  • Page 15 Loveseat Assembly (continued) CONNECTING THE ARMS TO THE BACKREST Turn the loveseat right side up. Connect the back of the right and the left arm (A & B) to the loveseat back (H) using M6x50 combination bolts (CC). Do not tighten all the bolts at this step. HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON...
  • Page 16 Loveseat Assembly (continued) CHECKING THE LOVESEAT Once all of the bolts are in place, fully tighten the bolts. Ensure all connections are secure before use. Place the seat cushions (F) and the back cushions (E) to finish the assembly of the loveseat.

  • Page 17: Coffee Table Assembly

    Coffee Table Assembly ATTACHING THE TABLE LEGS TO THE TABLE TOP Place the table top (I) upside down on a soft surface. Attach the table legs (J) to the table top (I) using M6x20 combination bolts (AA). Do not fully tighten all bolts at this step. HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON...
  • Page 18 Coffee Table Assembly (continued) CONNECTING THE LEG CONNECTOR TO THE TABLE LEGS Attach the leg connector (K) to the table legs (J) using M6x40 combination bolts (BB). Do not fully tighten all the bolts at this step.

  • Page 19: Care And Cleaning

    Coffee Table Assembly (continued) CHECKING THE COFFEE TABLE Once all of the bolts are in place, fully tighten the bolts using the hex wrench (DD). Turn the coffee table right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the seating set with a damp cloth and dry thoroughly.
  • Page 20 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
