Yale Digital Leverset
Installation Guide & User Manual
Please read the instructions before fitting and using the Yale Digital Leverset.
The functions and design of this product can be changed
without prior notice for performance and quality improvements.
An ASSA ABLOY Group Brand
YDLR/BLK and YDLL/BLK Issue 1 0719
Advertisement
Table of Contents
Related Manuals for Assa Abloy Yale YDLL/BLK
Summary of Contents for Assa Abloy Yale YDLL/BLK
- Page 1 Please read the instructions before fitting and using the Yale Digital Leverset. The functions and design of this product can be changed without prior notice for performance and quality improvements. An ASSA ABLOY Group Brand YDLR/BLK and YDLL/BLK Issue 1 0719...
-
Page 2: Table Of Contents
Contents Before Installation Introduction Components Specifications Door Preparation Getting Started Drilling Latch Preparation Fitting External Furniture Fitting Internal Furniture Fit Strike Registering Credentials Removing Credentials Usage Lock Features Security Features Feature Programming User Key Tag Log User Log Customer Service Help... -
Page 3: Introduction
Introduction Thank you for choosing the Yale Digital Leverset Door Lock. This installation guide and user manual will enable you to operate the product safely and to its full potential. Please ensure you read this manual completely before using the Yale Digital Leverset Door Lock. The information included in this manual is accurate at the time of publication. -
Page 4: Components
USER MANUAL Before Installation Components Yale EC800 Digital Leverset Components USER MANUAL Before Installation Registering Credentials Review inventory before starting install. Components Register User PIN Code Exterior Furniture Interior Furniture 60mm Backset Latch Strike Box Strike Key Tag x 2 Key x 2 M4x44mm 44mm Timber... -
Page 5: Door Preparation
Door Preparation • Ensure your door is 35-51mm thick. • Position Door Template at the desired lock height (Recommend 1m from the floor) and mark with a pencil all holes, including the latch hole. • If retrofitting using an existing 54mm cylinder hole, use the template to mark the position of the 14mm hole. -
Page 6: Latch Preparation
Latch Preparation • Slide latch into the 25mm hole and mark around latch faceplate. • Remove latch and chisel out face plate recess to a depth of 3.5mm. • Insert latch with angled face of bolt towards proposed strike position and fasten with two of the 20mm screws provided. -
Page 7: Fitting Internal Furniture
Internal Furniture Fitting Internal Furniture Gasket M4 Screw holes Remove the two small M4 screw located under the panel. Then remove the rubber gasket and metal plate 1. Remove Mounting Plate Internal of Inside Panel. Furniture • Remove the two short M4 screws on the Internal Gasket Furniture... - Page 8 Fitting Internal Furniture 3. Fitting Internal Furniture • Connect cable to mating connector on Internal Furniture. Internal Furniture • Slide the Internal Furniture onto Mounting Plate taking care to not pinch the cable as sket M4 Screw holes it may become damaged. the two small M4 screw located under the IMPORTANT TIP: Insert the key into the handle and test the en remove the rubber gasket and metal plate...
-
Page 9: Fit Strike
Fit Strike • Partially close door and mark position of latch bolt to determine striker height. Mark and mortice door jamb to suit the striker box and striker. • Drill the 2.5mm pilot holes for both striker box and striker. •... -
Page 10: Registering Credentials
Before Installation Before Installation Registering Credentials Registering Credentials Components Register User PIN Code Yale EC800 Digital Leverset Components Components Register User PIN Code Register User PIN Code Yale EC800 Digital Leverset USER MANUAL Registering Credentials USER MANUAL Before Installation Registering Credentials Before Installation Registering Credentials Components... -
Page 11: Removing Credentials
Registering Credentials Removing Credentials Register User PIN Code Deleting a Key Fob Removing Credentials Registering Credentials Removing Credentials Registering Credentials Removing Credentials Deleting a Key Fob Register User PIN Code Register User PIN Code Deleting a Key Fob Deleting a Key Tag ●... -
Page 12: Usage
unction Usage Usage Removing Credentials ery alarm Deleting a Key Fob Open Door by PIN Code Unlocking the Door via PIN Code Unlock Indicator • Touch the keypad to wake up the lock, then enter PIN code (6-10 digits) and press "... - Page 13 (A long “beep” sound will be heard, if the deleting light will become red and fresh.) successfully.) ttery alarm Three short “beep” sounds will be heard if the KeyCard has no data for delete. nction Unlock Indicator Note: The lock will exit the setting mode after 8 seconds if no operation or press “...
-
Page 14: Lock Features
Unlock Indica Lock Features All dimensions in millimetres High Security Mode turn on Built In Function Low Battery Alarm Low battery alarm Open the Door by both PIN Code and KeyCard) Unlock Indicator Low Battery • When the lock detects low battery Indicator Key Tag Indicator power, an "... - Page 15 tion Unlock Indicator Low Battery Indicator Key Tag Indicator Zone alarm Lock Features Unlock Indicator All dimensions in millimetres Press and release “SET” button three times. High Security Mode turn on Built In Function ● Unlock Indicator Low battery alarm Then press “#”...
- Page 16 Lock Features Lock Soft Reset • In case the lock is not responsive to a PIN code entry or Key Tag credential and after verifying the batteries are not flat a soft reset may be required. • To perform a soft reset of the lock press the "Reset"...
-
Page 17: Feature Programming
Yale EC800 Digital Leverset Feature Programming USER MANUAL Yale EC800 Digital Leverset Advanced Function Disable Automatic Locking (Passage Mode) Passage Mode turn on (Door without locking) USER MANUAL Before Installation • Disable Automatic Locking (Passage Function Components Mode) by entering the PIN code or Unlock Indicator tapping a Key Tag on the keypad, followed by pressing "... - Page 18 Yale EC800 Digital Leverset Yale EC800 Digital Leverset Feature Programming USER MANUAL All dimensions in millimetres Advanced Function High Security Mode turn on USER MANUAL All dimensions in millimetres Passage Mode turn on (Door without locking) Advanced Function (Open the Door by both PIN Code and KeyCard) High Security Mode turn on Enable High Security Mode Passage Mode turn on...
-
Page 19: User Key Tag Log
User Key Tag Log Slot Number Name... - Page 20 User Key Tag Log Slot Number Name...
-
Page 21: Customer Service
Web: www.yalelock.co.nz Email nz.sales@assaabloy.com Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group Company. Compliance – Australia & New Zealand This product complies with all the applicable requirements of the Regulatory Compliance Mark (RCM) for Australia. - Page 22 Notes...
- Page 23 Notes...
- Page 24 ASSA ABLOY Australia Pty Limited (“ASSA ABLOY”) recommends that you consult ASSA ABLOY or its agents prior to placing an order to ascertain current information on specific products, as ASSA ABLOY reserves the right to make changes without notice. ASSA ABLOY will not be liable for any injury, loss or damage whatsoever, arising from any errors or omissions in the information contained in the brochure or arising from the use or application of the information contained herein.
