Installing Ethernet Routing Switch 5900
Series
Release 7.5
NN47211-300
Issue 06.02
December 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5900 Series and is the answer not in the manual?

Questions and answers

Related Manuals for EXTREME SWITCHING 5900 Series

Summary of Contents for EXTREME SWITCHING 5900 Series

  • Page 1 Installing Ethernet Routing Switch 5900 Series Release 7.5 NN47211-300 Issue 06.02 December 2017...
  • Page 2 © REPRESENT THAT YOU HAVE THE AUTHORITY TO BIND SUCH 2017, Extreme Networks, Inc. ENTITY TO THESE TERMS OF USE. IF YOU DO NOT HAVE SUCH All Rights Reserved. AUTHORITY, OR IF YOU DO NOT WISH TO ACCEPT THESE Notice TERMS OF USE, YOU MUST NOT ACCESS OR USE THE HOSTED SERVICE OR AUTHORIZE ANYONE TO ACCESS OR While reasonable efforts have been made to ensure that the...
  • Page 3 including any code and software unless expressly authorized by THE PERSONAL USE OF A CONSUMER OR OTHER USES IN Extreme Networks. Unauthorized reproduction, transmission, WHICH IT DOES NOT RECEIVE REMUNERATION TO: (I) ENCODE dissemination, storage, and or use without the express written VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC consent of Extreme Networks can be a criminal, as well as a civil VIDEO”) AND/OR (II) DECODE AVC VIDEO THAT WAS ENCODED...
  • Page 4 For additional information on Extreme Networks trademarks, please see: http://www.extremenetworks.com/company/legal/...

  • Page 5: Table Of Contents

    ...................  8 Subscribing to service notifications Chapter 2: New in this document....................  9 Chapter 3: Preinstallation checklist.................. 10 Chapter 4: Installation preparation.................. 12 ................ 12 Ethernet Routing Switch 5900 series models .................. 18 Electrostatic discharge prevention ...................... 19 Technical specifications ...................... 21 Power specifications ........................ 24...

  • Page 6: Chapter 1: Preface

    Purpose This document provides the information and procedures required to install the hardware, software, cabling, and power for the Extreme Networks Ethernet Routing Switch 5900 Series. Unless otherwise indicated, this information applies to: • Extreme Networks Ethernet Routing Switch 5928GTS •...

  • Page 7: Getting Help

    Go to the Avaya Support website at http://support.avaya.com for the most up-to-date documentation, product notices, and knowledge articles. You can also search for release notes, downloads, and resolutions to issues. Use the online service request system to create a service December 2017 Installing ERS 5900 Series...

  • Page 8: Extreme Networks Documentation

    5. Type your job title. 6. Select the industry in which your company operates. 7. Confirm your geographic information is correct. 8. Select the products for which you would like to receive notifications. 9. Click Submit. December 2017 Installing ERS 5900 Series...

  • Page 9: Chapter 2: New In This Document

    Chapter 2: New in this document There are no feature changes in this release. December 2017 Installing ERS 5900 Series...

  • Page 10: Chapter 3: Preinstallation Checklist

    Chapter 3: Preinstallation checklist Before you install the ERS 5900 Series, make sure that you complete the tasks in the preinstallation checklist. Task Description Review the technical specification for For the physical, electrical, and the switch. Make sure that the area...
  • Page 11 Depending on the switch model, see Installing ERS 5900 switch in an equipment rack on page 39 or Installing ERS 59100GTS and ERS 59100GTS- PWR+ in an equipment rack page 41. December 2017 Installing ERS 5900 Series...

  • Page 12: Chapter 4: Installation Preparation

    Chapter 4: Installation preparation Ethernet Routing Switch 5900 series models The following table lists the different Ethernet Routing Switch 5900 Series models and the key features for each switch. Table 1: 5900 Series Switch Platforms 5900 Series Switch Model Key features...
  • Page 13 Ethernet Routing Switch 5900 series models 5900 Series Switch Model Key features Part Number serviceable power supply receptacles, which support 450 W AC power supply modules. Ethernet Routing Switch 5928GTS- • 24 10/100/1000 Base-T RJ-45 AL590002A-E6 (no PSU, no PC) PWR+ ports with 802.3at PoE+...
  • Page 14 Installation preparation 5900 Series Switch Model Key features Part Number receptacles, which support 450 W AC power supply modules. Ethernet Routing Switch 5952GTS- • 48 10/100/1000 Base-T RJ-45 AL590004A-E6 (no PSU, no PC) PWR+ ports with 802.3at PoE+ AL5900A4B-E6 (no PC) •...
  • Page 15 Front to Back cooling (for example, AL5900E4F-E6). Common hardware features The following hardware features are part of all 5900 Series switches: • One RJ-45 RS-232 Console connection at the front (note jack orientation) • Two FRU Fan Tray modules Note: ERS 59100GTS and ERS 59100GTS-PWR+ support four Fan Tray modules.
  • Page 16 5. QSFP ports for stacking The following figure shows the front panel of the 59100GTS switch. 1. Console port 2. USB 2.1 Type-A port 3. LED display The following figure shows the rear panel of the 59100GTS switch. December 2017 Installing ERS 5900 Series...
  • Page 17 Support is not extended to third-party devices that do not comply with these standards. Consult the documentation provided with the USB drive to ensure compliance with these standards. Important: The micro-USB port on the front panel of the Ethernet Routing Switch 5900 Series models is not enabled. December 2017...

  • Page 18: Electrostatic Discharge Prevention

    • Do not remove the wrist or ankle strap until the installation is complete. With new cable installations, you should use an ESD discharge cable to reduce the potential for damage from static that can build up in cables. See the following figure. Figure 1: ESD cable December 2017 Installing ERS 5900 Series...

  • Page 19: Technical Specifications

    Technical specifications Technical specifications The following table provides the technical specifications for the individual switches in the Ethernet Routing Switch 5900 Series. Ensure that the area where you install the switch and where it operates meets these requirements. Warning: To avoid bodily injury from hazardous electrical shock and current, never remove the top of the device.
  • Page 20 The system should never exceed 70dBA. Miscellaneous Operating • No heat sources such as hot air vents or direct sunlight located near Considerations the switch • No sources of severe electromagnetic interference located near the switch. Table continues… December 2017 Installing ERS 5900 Series...

  • Page 21: Power Specifications

    • Adequate clearance is allotted at the front and rear of the switch for access to cables. Power specifications This section provides the following specifications for Ethernet Routing Switch 5900 Series. The following table describes the AC power specifications. Table 5: AC power specifications...
  • Page 22 4 PSU 1400 200–240 3218.9 14.1 322.1 1099.0 W/PSU 3 PSU 3227.7 14.1 330.5 1127.6 2 PSU 3158.7 13.8 353.8 1203.7 1 PSU 1643.3 7.2 202.8 692.0 The following table provides typical power consumption. December 2017 Installing ERS 5900 Series...
  • Page 23 2 PSU 1400 200–240 1 PSU ERS 5928GTS-uPWR 2 PSU 1000 100–120 1440 1 PSU 2 PSU 1400 200–240 1440 1 PSU 1200 ERS 5952GTS-PWR+ 2 PSU 1000 100–120 1440 1 PSU Table continues… December 2017 Installing ERS 5900 Series...

  • Page 24: Mtbf Values

    200–240 1440 1 PSU 1200 MTBF values The following table lists the MTBF values for the switches in ERS 5900 Series when two or four fans are used in combination with PSUs. Model Number of PSUs Power Supply rating MTBF (hours)

  • Page 25: Power Supply Cords

    Two modular power supplies are supported and each power supply has its own power cord. The Ethernet Routing Switch 5900 Series models that support PoE use 1000 W or 1400 W power supply, this power supply is unique to Ethernet Routing Switch 5900 Series. The power adapter on 1000 W or 1400 W power supply utilizes an IEC 60320 C16 connector.
  • Page 26 Back to Front Airflow ERS 5928GTS-PWR+ AL1905A3F-E6 Front to Back Airflow ERS 5928GTS-PWR+ AL1905A3B-E6 Back to Front Airflow ERS 5928GTS-uPWR AL1905A3F-E6 Front to Back Airflow ERS 5928GTS-uPWR AL1905A3B-E6 Back to Front Airflow Table continues… December 2017 Installing ERS 5900 Series...
  • Page 27 Power cord 2.5 m IEC C13 to AS Australia 3112 AA0020069E6 Power cord 2.5 m IEC C13 to JIS Japan 8303 AA0020101-E6 Power cord 2.5 m IEC C13 to NBR Brazil 14136 (IEC 60906-1) Table continues… December 2017 Installing ERS 5900 Series...
  • Page 28 Power cord 2.5 m IEC C15 to North America NEMA L6-15P TWIST LOCK AA0020109-E6 Power cord 2.5 m IEC C15 to India BS-546 AA0020110-E6 Power cord 2.5 m IEC C15 to Argentina IRAM 2073 December 2017 Installing ERS 5900 Series...
  • Page 29 Depending on the switch model, see the following sections: Switch Model Section ERS 5928GTS, ERS 5952GTS-PWR+, ERS ERS 5900 switch package contents on page 30 5928GTS-PWR+, ERS 5928GTS-uPWR, ERS 5928MTS-uPWR ERS 59100GTS, ERS 59100GTS-PWR+ ERS 59100 switch package contents on page 31 December 2017 Installing ERS 5900 Series...
  • Page 30 Installation preparation ERS 5900 switch package contents December 2017 Installing ERS 5900 Series...

  • Page 31: Cooling Fans And Power Supplies

    Switch requires one fan tray and one power supply unit. To provide redundancy, the supported number of power supplies and fan trays can be installed. The following table lists the switch model and the supported number of fan trays and power supply units: December 2017 Installing ERS 5900 Series...
  • Page 32 If you are using front to back cooling or back to front cooling, ensure that you use compatible power supplies that match the cooling fan airflow. The following figure shows AC power supply. December 2017 Installing ERS 5900 Series...

  • Page 33: Installing The Fan Trays And Power Supply

    The optional power supply unit can be installed for redundancy and load sharing. For more information, see Supported number of fan trays and power supplies on page 32. The following figures show fan trays and power supply location: December 2017 Installing ERS 5900 Series...
  • Page 34 Installation preparation Figure 4: ERS 59100GTS and ERS 59100GTS-PWR+ rear panel Figure 5: ERS 5900 Series rear panel Fan Tray 2 Fan Tray 1 Power Supply Unit 1 (PS 1) Power Supply Unit 2 (PS 2) Fan Tray 4 Fan Tray 3...
  • Page 35 Example The following figures show how to properly insert the cooling fan trays and power supplies into your switch. Figure 6: Installing the fan trays and power supplies in ERS 59100GTS and ERS 59100GTS-PWR+ December 2017 Installing ERS 5900 Series...

  • Page 36: Connecting Ac Power

    Installation preparation Figure 7: Installing the fan trays and power supplies in ERS 5900 Series Next steps After you install the two fan trays and at least one power supply, you can install and connect power to the switch. Connecting AC power Perform the following procedure to connect an AC power source to the switch.
  • Page 37 The only way to turn off the switch is to disconnect the power. Always connect the AC power cord in a location that can be reached quickly and safely in case of an emergency. December 2017 Installing ERS 5900 Series...

  • Page 38: Chapter 5: Switch Installation

    45 mount brackets and then, slide the switch. The brackets secure the chassis and prevent it from sliding around during vibration or when inserting or extracting transceivers. December 2017 Installing ERS 5900 Series...

  • Page 39: Installing Ers 5900 Switch In An Equipment Rack

    2. Attach a bracket to each side of the switch with the included screws. You have different options for front and rear mounting positions. Attach the brackets in the best position for your specific equipment rack. Figure 8: Front-mounted rack bracket installation December 2017 Installing ERS 5900 Series...
  • Page 40 Switch installation Figure 9: Rear-mounted rack bracket installation 3. Slide the switch into the rack. 4. Insert and tighten the rack mount screws. Figure 10: Front-mounted rack installation December 2017 Installing ERS 5900 Series...

  • Page 41: Installing Ers 59100Gts And Ers 59100Gts-Pwr+ In An Equipment Rack

    Installing ERS 59100GTS and ERS 59100GTS-PWR+ in an equipment rack About this task Install ERS 59100GTS and ERS 59100GTS-PWR+ on an equipment rack. To install other switches in ERS 5900 Series, see Installing ERS 5900 switch in an equipment rack on page 39. Before you begin Tool requirements •...
  • Page 42 2. Attach a bracket to each side of the switch with the included screws. You have different options for front and rear mounting positions. Attach the brackets in the best position for your specific equipment rack. Figure 12: Front-mounted rack bracket installation December 2017 Installing ERS 5900 Series...
  • Page 43 Installing ERS 59100GTS and ERS 59100GTS-PWR+ in an equipment rack Figure 13: Rear-mounted rack bracket installation 3. Slide the switch into the rack. December 2017 Installing ERS 5900 Series...
  • Page 44 Switch installation Figure 14: Front-mounted rack installation December 2017 Installing ERS 5900 Series...

  • Page 45: Installing The Switch Using Optional Four-Post Rack-Mount Brackets

    Perform this procedure to assemble and install the four-post rack-mount bracket kit. Before you begin ERS 5900 Series four-post server rack-mount kit — AL5911001-E6 Tool requirements • Phillips screwdriver to attach brackets to the switch and the switch to the rack.
  • Page 46 Verify that you have all the screws and brackets to assemble and install the four-post rack mount kit. Figure 16: Four-post rack-mount kit assembly Procedure 1. Attach a front bracket to each guide bracket with four 8.5 mm length flat head machine screws. December 2017 Installing ERS 5900 Series...
  • Page 47 Installing the switch using optional four-post rack-mount brackets 2. Attach the guide brackets to the switch chassis. Figure 17: Attaching guide brackets to ERS 5900 switch December 2017 Installing ERS 5900 Series...
  • Page 48 Test fit the rear mounting brackets in the guide brackets and verify that the rear brackets can slide in the channels. Remove the rear brackets. 3. Install the switch into the equipment rack, temporarily using only the front rack mounts and screws. December 2017 Installing ERS 5900 Series...

  • Page 49: Single And Multiple Switch Arrangements

    Figure 20: Attach ERS 5900 switch rear mounting brackets You can proceed with the installation by connecting power and network connections to the switch. Single and multiple switch arrangements This module describes standalone and stacked arrangements. December 2017 Installing ERS 5900 Series...
  • Page 50 Switch installation You can stack any of the switches in the ERS 5900 Series. You can connect up to eight switch devices that are in one Rack Unit (RU) height in a stack to provide uninterrupted connectivity for up to 384 ports.
  • Page 51 (via the Cascade Down cable) becomes unit 2 (and the next unit is unit 3 and so on), until the maximum stack configuration (up to eight units for an ERS 5900 Series stack and up to four units for an ERS 59100 stack) is reached. If the base unit is changed to another unit in the stack, the new base unit keeps its original unit number in the stack.
  • Page 52 In this configuration, the base unit discovers the stack in a cascade down (stack down) direction. The following illustration shows a cascade down (stack down) configuration for ERS 5900 switch series. The ERS 59100 switch can be connected similarly. December 2017 Installing ERS 5900 Series...
  • Page 53 4 = 1.0m Cascade/Stack cable (Return cable) Figure 23: ERS 5900 cascade down configuration Note: Return cable length may vary depending on unit spacing. Ensure you order the proper length return cable to provide adequate strain relief. December 2017 Installing ERS 5900 Series...
  • Page 54 Unit 2. The stack is wired upward through the units and the system continues to number in this manner throughout the stack. In this configuration, the base unit discovers the stack in a cascade up (stack up) direction. The following illustration shows a cascade up (stack up) configuration. December 2017 Installing ERS 5900 Series...
  • Page 55 Figure 24: Cascade up configuration Note: Return cable length may vary depending on unit spacing. Ensure you order the proper length return cable to provide adequate strain relief. For stack installation procedures, see Stack configuration on page 57. December 2017 Installing ERS 5900 Series...
  • Page 56 Redundant cascade stacking The 5900 Series switches allow a stack of up to eight units in a 5900 Series stack. If any single unit fails or if a cable is accidently disconnected, other units in the stack remain operational without interruption.

  • Page 57: Stack Configuration

    You can change base unit switches with switches on (hot), but changes do not take affect until switches are rebooted. Selecting a base unit About this task This procedure describes the steps to select a base unit. December 2017 Installing ERS 5900 Series...
  • Page 58 Standard, ANSI/TIA/EIA 568-B fitted with an RJ-45 Module Jack. Console Port Serial cable with a DB-9 female connector on both ends. The maximum length for the console port cable is 25 feet (8.3 meters). Table continues… December 2017 Installing ERS 5900 Series...

  • Page 59: Connecting A Transceiver To The Switch Or Switch Stack

    The following sections describe small form factor pluggable (SFP) transceivers in the Ethernet Routing Switch 5900 Series. For installation and removal procedures, see Installing Transceivers and Optical Components on Ethernet Routing Switch 4900 and 5900 Series. Installing transceivers About this task This procedure describes the steps used to install transceivers.

  • Page 60: Supported Optical Devices

    For more information about SFP and SFP+ transceivers, including technical specifications and installation instructions, see Installing Transceivers and Optical Components on Ethernet Routing Switch 4900 and 5900 Series. Small form-factor pluggable (SFP) transceivers SFPs are hot-swappable input and output enhancement components designed to allow gigabit Ethernet ports to link with other gigabit Ethernet ports over various media types.
  • Page 61 10GBASE CWDM DDI SFP+ (40 40 km, 1471 to 1611 nm AA1403153–E6 to AA1403160–E6 10GBASE CWDM DDI SFP+ (70 70 km, 1471 to 1611 nm AA1403161–E6 to AA1403168–E6 10GBASE-BX10 SFP+ 10 km AA1403169–E6 and AA1403170– December 2017 Installing ERS 5900 Series...

  • Page 62: Checking Status Leds To Verify Switch Installation

    For more information about minimum insertion losses for optical products, see Installing Transceivers and Optical Components on Ethernet Routing Switch 4900 and 5900 Series. Locating end of sale notices To view the End of Sale notices, go to one of the following Websites: •...
  • Page 63 The unit is operating as the Temporary Base unit. Amber (Blinking) The unit has a Base unit election problem. Multiple units are configured with a Base unit switch on, or no unit has the Base unit switch Table continues… December 2017 Installing ERS 5900 Series...
  • Page 64 The power supply in slot 1, 2, 3, or 4 is installed, but not providing power to the switch (non-service-affecting). Emerald (Solid) The power supply in slot 1, 2, 3, or 4 is operating normally. Table continues… December 2017 Installing ERS 5900 Series...
  • Page 65 Sapphire / Ruby (Alternating) The fan tray in position 1, 2, 3, or 4 does not match the back to front airflow mode of the Table continues… December 2017 Installing ERS 5900 Series...

  • Page 66: Ip Address Information Configuration

    • Serial cable with a DB-9 female connector on both ends. The maximum length for the console port cable is 25 feet (8.3 meters). Procedure 1. Connect one end of serial cable to the DB-9 connector on the terminal. December 2017 Installing ERS 5900 Series...
  • Page 67 3. In the In-Band Subnet Mask field enter the appropriate subnet mask in dotted-decimal notation. 4. In the Default Gateway field, enter the appropriate default gateway in dotted-decimal notation. 5. Press CTRL + C to return to the main menu. December 2017 Installing ERS 5900 Series...
  • Page 68 None Flow Control None Assigning IP parameters using Enterprise Device Manager About this task The following procedure describes how to use Quick Start to assign IP parameters to the Ethernet Routing Switch 5900 Series. December 2017 Installing ERS 5900 Series...
  • Page 69 • Ensure the terminal from which you ping the switch is on the same network as the switch. Procedure Ping the 5900 Series switch from a terminal or workstation that is on the same network. If the network device sends a ping reply, a message indicates that the specified IP address is alive and can communicate with other devices.

  • Page 70: Chapter 6: Installation Reference

    Chapter 6: Installation reference About this task This section provides reference information for the Ethernet Routing Switch 5900 Series. Console and management connections The left front panel of the switch contains the Status LEDs, Console port, Out of Band Management port, and a USB 2.1 port, as well as a micro-USB Type B port (reserved).

  • Page 71: Rj-45 Connector Pin Assignments

    IP and gateway for remote management. For more information about Out of Band Management configuration, see Quick Start Configuration for Ethernet Routing Switch 4900 and 5900 Series. USB port The USB port is a Standard Type-A female USB 2.1 port. The switch provides USB host functionality and can support USB flash drives.

  • Page 72: Ethernet Routing Switch 5900 Series Poe

    TP3- TP1- TP0- TP3+ TP2+ TP3- TP2- Ethernet Routing Switch 5900 Series PoE The following table outlines the RJ-45 connector pin assignments in the Ethernet Routing Switch 5900 Series PoE switches. Connector Pin Number Signal for 10/100Base-T Signal for 10/100Base-T...

  • Page 73: Chapter 7: Translations Of Safety Messages

    Chapter 7: Translations of safety messages This module contains translations of the safety messages found in the Ethernet Routing Switch 5900 Series documentation suite. Safety messages Caution: When mounting this device in a rack, do not stack units directly on top of one another in the rack.
  • Page 74 Important: Attenzione: Se nello slot non vengono installati moduli, assicurarsi di mantenere la piastra di copertura metallica in sede sopra lo slot. La rimozione della piastra impedisce la ventilazione e il corretto raffreddamento dell’unità. December 2017 Installing ERS 5900 Series...
  • Page 75 Important: Vorsicht: Verwenden Sie nur Netzkabel mit Schutzerdung. Ohne ordnungsgemäße Schutzerdung besteht für Personen, die den Switch berühren, die Gefahr eines elektrischen Schlages. Eine nichtvorhandene Schutzerdung kann zu sehr starken Abstrahlungen führen. December 2017 Installing ERS 5900 Series...
  • Page 76 Senza un’adeguata messa a terra, chiunque tocchi lo switch corre il rischio di ricevere una scossa elettrica. L’assenza di un percorso per la messa a terra verso lo switch può comportare un eccesso di emissioni. December 2017 Installing ERS 5900 Series...
