EXTREME SWITCHING 5900 Series Installation Job Aid

Ethernet routing switch
Hide thumbs Also See for 5900 Series:

Advertisement

Quick Links

Download this manual
Installation Job Aid for Ethernet Routing
Switch 5900 Series
Notices
Notice paragraphs alert you about issues that require your attention. The following paragraphs
describe the types of notices used in this guide.
Note:
Notes provide tips and useful information regarding the installation and operation of products.
Electrostatic alert:
ESD
ESD notices provide information about how to avoid discharge of static electricity and
subsequent damage to products.
Caution:
Caution notices provide information about how to avoid possible service disruption or damage to
products.
Warning:
Warning notices provide information about how to avoid personal injury when working with
products.
Voltage:
Danger — High Voltage notices provide information about how to avoid a situation or condition
that can cause serious personal injury or death from high voltage or electric shock.
Danger:
Danger notices provide information about how to avoid a situation or condition that can cause
serious personal injury or death.
©
2017, Extreme Networks, Inc.
All Rights Reserved.
NN47211-301
Issue 05.01
November 2017
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5900 Series and is the answer not in the manual?

Questions and answers

Related Manuals for EXTREME SWITCHING 5900 Series

Summary of Contents for EXTREME SWITCHING 5900 Series

  • Page 1 Installation Job Aid for Ethernet Routing Switch 5900 Series NN47211-301 Issue 05.01 November 2017 Notices Notice paragraphs alert you about issues that require your attention. The following paragraphs describe the types of notices used in this guide. Note: Notes provide tips and useful information regarding the installation and operation of products.

  • Page 2: Safety Messages

    Fiber optic equipment can emit laser or infrared light that can injure your eyes. Never look into an optical fiber or connector port. Always assume that fiber optic cables are connected to a light source. November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...

  • Page 3: Ac Power Cord Specifications

    • BS1363 male plug with fuse • 50 Hz • Harmonized cord • Single Phase Australia: • 240 VAC • AS3112-1981 male plug • 50 Hz • Single Phase November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...

  • Page 4: Installation Preparation

    The following figures show fan trays and power supply location: Figure 1: ERS 59100GTS and ERS 59100GTS-PWR+ rear panel Figure 2: ERS 5900 Series rear panel November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 5 4. Verify that each power supply is fully seated in the slot and securely clipped in place. Example The following figures show how to properly insert the cooling fan trays and power supplies into your switch. November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 6 Figure 3: Installing the fan trays and power supplies in ERS 59100GTS and ERS 59100GTS-PWR+ November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 7 Installing ERS 5900 Series in an equipment rack About this task Perform this procedure to install all switches in ERS 5900 Series except ERS 59100GTS and ERS 59100GTS-PWR+. To install these switches, see Installing ERS59100GTS and ERS59100GTS-PWR+ in an equipment rack on page 13.
  • Page 8 2. Attach a bracket to each side of the switch with the included screws. You have different options for front and rear mounting positions. Attach the brackets in the best position for your specific equipment rack. November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 9 Figure 5: Front-mounted rack bracket installation November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 10 Figure 6: Rear-mounted rack bracket installation 3. Slide the switch into the rack. 4. Insert and tighten the rack mount screws. Figure 7: Front-mounted rack installation November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 11 For four-post equipment rack installations, an optional four-post rack mounting kit (AL5911001-E6, sold separately) is available that includes adjustable rear brackets. For more information, see Installing Ethernet Routing Switch 5900 Series. November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 12 Figure 9: Rack mount attachment screws Figure 10: Optional four-post rack mount brackets November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 13 59100GTS-PWR+ in an equipment rack About this task Perform this procedure to Install ERS 59100GTS and ERS 59100GTS-PWR+ in an equipment rack. To install other switches in ERS 5900 Series, see Installing ERS 5900 Series in an equipment rack on page 7.
  • Page 14 Figure 11: Front-mounted rack bracket installation Figure 12: Rear-mounted rack bracket installation November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 15 3. Slide the switch into the rack. Figure 13: Front-mounted rack installation November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 16 6. For four-post equipment rack installations, an optional four-post rack mounting kit (AL5911001-E6, sold separately) is available that includes adjustable rear brackets. Attach a front bracket to each guide bracket with four M2 x 3-millimeter-long flathead machine screws. November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
  • Page 17 Figure 15: Rack mount attachment screws 7. Attach the guide brackets to the switch chassis. November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...

  • Page 18: Connecting Ac Power

    Connecting AC power The Ethernet Routing Switch 5900 Series does not have a power switch. When you connect the AC power cord to a suitable AC power outlet, the switch powers up immediately. Connect the AC power cord to the back of the switch, and then connect the cord to a power outlet.
  • Page 19 Figure 17: Connecting the AC power cord to the Ethernet Routing Switch 5900 Series November 2017 Installation Job Aid for Ethernet Routing Switch 5900 Series...
