Blade Assembly - MULTIQUIP J36E2 Operation And Parts Manual

NO. PART NO.
1% 0164 B
2% 0166 A
3% 1157 A
4% 1161-1
5% 1162 A
6% 1163-1
7% 1316
8% 1322
9% 1456
10% 1875
11% 1876
12% 2826-1
13% 4164
14% 12097
15 1215
16 10968
17$ 12208
18$ 12778
19$ 10793
20$# 1471
21$ 1154 A
22@ 21906
23 23647
24
25 1817
J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 47
PART NAME
SCREW, HHC ROUNDED 3/8-16" SPCL
LOCK WASHER 3/8" MED
BUSHING, TROWEL ARM
SPIDER PLATE, SILVER
CAP, GREASE ZERK #2 YELLOW
LEVER, TROWEL ARM RH, SILVER
SPRING, LS ARM RETURN
RETAINING SCREW ASSY.
NUT, HEX FINISH 3/8-16
WASHER, INT. SHKP. 3/8"
NUT, HEX JAM 3/8-16 CLASS 2B
ARM, TROWEL, 9-3/4", SILVER
ROLL PIN 5/16" X 1-3/4"
SCREW, SQHS 3/8 -16 X 1-3/4" CONE GRD 8
SPIDER PLATE ASSY. .......................................1................INCLUDES ITEMS W/%
THRUST BEARING KIT .....................................1................INCLUDES ITEMS W/$
WEAR RING
FLANGE BEARING
THRUST COLLAR ............................................1................INCLUDES ITEMS W/#
THRUST COLLAR BUSHING
WEAR PLATE
SCREW, HHCS 5/16-18 X 1-3/4"
KIT, BOLT SAE BLADE ......................................1................INCLUDES ITEMS W/@
BLADE ASSEMBLY ...........................................4................CONTACT DISCOUNT-
..............................................................................................EQUIPMENT
TOOL, TROWEL ARM ADJUST. FIXTURE
SPIDER ASSY.
QTY. REMARKS
4
4
4
1
4
4
4
4
1
4
4
4
4
1
1
1
1
1
12
1
