PAGE 40 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
SWITCH AND CONDUIT ASSY.
1
2
2
NOTES:
ITEM 16 INCLUDES ALL ITEMS REFERENCED
1
ON THIS PAGE AND ITEM 25 ON THE CONTROL
AND HANDLE ASSY.
FOR ELECTRICAL CONNECTIONS REFERENCE
2
OPERATOR'S MANUAL FOR ELECTRICAL WIRING
DIAGRAM.
3
CONNECT TO ELECTRIC MOTOR HOUSING.
2
