MULTIQUIP J36E2 Operation And Parts Manual page 39

NO. PART NO.
1@ 1112
2#@ 1113
3#@ 0786A
4#@ 0786
5#@ 1114
6#@ 1115
7#@ 1116
8@ 1110
9%@ 3615
10%@ 1111
11%@ 0786
12%@ 0281
13%@ 1478
14%@ 0122 C
15%@ 20817
16@ 4634
17@ 1907
18@ 10133
19@ 10136
20@ 1121
21@ 1117
22$@ 1118
23$@ 1119
24$@ B1790
25 1921
NOTICE
ITEM 25 INCLUDES ALL ITEMS REFERENCED ON
THIS PAGE AND ITEM 16 ON THE SWITCH AND
CONDUIT ASSY.
J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 39
PART NAME
SLIDE BLOCK AND CABLE ASSY. ...................1................INCLUDES ITEMS W/#
BLOCK, SLIDE
SPACER
SCREW, BHC 1/4-20 X 3/8" NYL PATCH ,NP 1
ROLL PIN 5/32" X1.3/8"
PITCH CONTROL CABLE ASSY, 47.25"
BRASS JAM NUT 5/16-18
CONTROL, TROWEL ASSY. .............................1................INCLUDES ITEMS W/%
SET COLLAR (W/SET SCREW)
BEARING
SCREW, BHC 1/4-20 X 3/8" NYL PATCH ,NP 1
BEARING
TROWEL CONTROL SHAFT
SCREW, SHS 3/8-16 X 1/2"
WHEEL, HAND PITCH CONTROL
HANDLE GRIP
HANDLE
LOCK NUT 3/8-16
FLAT WASHER 3/8"
SCREW, HHCS 3/8-16 X 2.3/4"
BLOCK, SUPPORT ASSY. .................................1................INCLUDES ITEMS W/$
PULLEY, PITCH CABLE
PIN, SUPPORT BLOCK
BLOCK, SUPPORT
HANDLE, ELECTRIC FINISHER ASSY. ............1................INCLUDES ITEMS W/@
CONTROL AND HANDLE ASSY.
QTY.
1
1
1
1
2
1
1
1
1
1
1
2
1
2
2
2
1
1
1
REMARKS
