OPERATION AND PARTS MANUAL
MODEL J36E2
WALK-BEHIND TROWEL
(2 HP ELECTRIC MOTOR)
Revision #1 (8/27/15)
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
PN: 23814

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J36E2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MULTIQUIP J36E2

Summary of Contents for MULTIQUIP J36E2

  • Page 1 OPERATION AND PARTS MANUAL MODEL J36E2 WALK-BEHIND TROWEL (2 HP ELECTRIC MOTOR) Revision #1 (8/27/15) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES. PN: 23814...
  • Page 2 We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,...

  • Page 3: Silicosis/Respiratory Warnings

    NIOSH/MSHA for the materials being used. PAGE 2 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 4: Table Of Contents

    Wiring Diagram (230 Vac) ........33 NOTICE Explanation Of Code In Remarks Column..... 34 Specifications and part numbers are subject to change Suggested Spare Parts ......... 35 without notice. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 3...

  • Page 5: Training Checklist

    Startup of machine, applying power. Maintaining a hover. Maneuvering. Pitching. Concrete fi nishing techniques. Shutdown of machine. Lifting of machine. Machine transport and storage. PAGE 6 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 6: Daily Pre-Operation Checklist

    Daily Pre-Operation Checklist       Gearbox oil level Condition of blades Blade pitch operation Safety stop switch operation Main ON/OFF switch operation J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 7...

  • Page 7: Safety Information

    Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE INJURY. NOTICE Respiratory hazards Addresses practices not related to personal injury. PAGE 8 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 8 T-Handle latch is locked (engaged). WARNING Training This machine to be operated by qualified personnel only. Ask for training as needed. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 9...
  • Page 9 „ No one other than the operator is to be in the working area when the equipment is in operation. „ DO NOT use the equipment for any purpose other than its intended purposes or applications. PAGE 10 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 10 Association of Equipment Manufacturers (AEM) can be obtained for a fee by ordering through their website at www.aem.org. Order FORM PT-160 J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 11...
  • Page 11 „ Use adequate lifting cable (strap or rope) of suffi cient strength. „ DO NOT lift machine to unnecessary heights. „ ALWAYS tie down equipment during transport by securing the equipment. PAGE 12 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 12: Trowel Specifications/Dimensions

    “normal ” circumstances. Values were obtained from concrete. Hearing protection is always recommended. all three axes of motion. The values shown represent the maximum RMS value from these measurements. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 13...

  • Page 13: Electric Motor Specifications

    Table 2. Electric Motor Specifications Model B697 Type HP/RPM 2.0 @3450 Phase Input Voltage 230/115 VAC Amps 8.4/16.6 Thermal Protection Insulation Class Ambient Temperature 104° F (40° C) PAGE 14 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 14: General Information

    See parts section of provide an outline for an experienced operator to provide this manual for a breakdown of the drive system. training to a new operator. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 15...

  • Page 15: Trowel Components

    VAC, 60 Hz single phase operation. For 230 VAC configuration refer to the electric motor wiring diagram within this manual. PAGE 16 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 16: Electric Motor

    2.0 HP 2.0 HP 115 VAC L5-20P L5-20R 230 VAC No. 14 No. 12 No. 12 No. 8 2.0 HP 230 VAC L6-20P L6-20R J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 17...

  • Page 17: Assembly And Installation

    3” (76 mm). YOKE YOKE EYELET BRASS SET BRASS SET NUT #1 NUT #2 Figure 7. Pitch Cable Yoke Attachment PAGE 18 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 18 ISO 680 (P/N 10139) PRESENCE gearbox lubricant oil until the oil filler hole overflows. ON/OFF LEVER SWITCH Figure 9. Operator Presence Switch J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 19...

  • Page 19: Starting

    1. Using an extension cord (Figure 10) of adequate size, plug one end of the extension cord into the trowel power plug. PAGE 20 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 20: Operation

    2. Place the main ON/OFF switch in the OFF position. 3. Remove extension cord from trowel power plug. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 21...
  • Page 21 NEVER place your feet or hands inside the guard rings ALWAYS keep clear of rotating or moving parts while operating this equipment. while starting or operating this equipment. PAGE 22 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 22: Options

    Figure 17. Trowel Arm Adjustment Fixture blade, allowing your finisher to float on “wet” concrete so that the troweling operation can begin as early as possible. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 23...

  • Page 23: Maintenance

    Visually examine the V-belt (Figure 18) and determine if it is full of tiny cracks, frayed, has pieces of rubber missing, SIDEWALL WEAR is peeling or otherwise damaged. Figure 18. V-Belt Inspection PAGE 24 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 24 (19 mm) thick FLAT steel “DISHED” EFFECT ON FINISHED CONCRETE plate should be used for testing. Figure 21. Incorrect Spider Plate Alignment J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 25...
  • Page 25 4. Install the new blades, maintaining the proper blade orientation for direction of rotation. Figure 22. Spider Removal 5. Reinstall the bolts and lock washers. PAGE 26 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 26 ROUND SHAFT SECTION TROWEL ARM Perform the following procedure when adjusting the trowel HEXAGONAL (HEX) SHAFT SECTION arm lever: Figure 25. Trowel Arm J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 27...
  • Page 27 2. Make sure that the bronze trowel arm bushing is not damage or out of round. Clean the bushing if necessary. If the bronze bushing is damaged or worn, replace it. PAGE 28 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 28 „ Clean all external parts of the trowel with a cloth. „ Cover the trowel and store in a clean, dry place. Figure 29. Pulley Orientation J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 29...
  • Page 29 Ball bearings LUBE SEAL SHAFT DISC in the manual control are permanently lubed. BUSHING Figure 30. Drive Pulley SET SCREW Components PAGE 30 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 30: Troubleshooting

    Check to ensure that each blade is adjusted to Blade Pitch? have the same pitch as all other blades. Adjust per maintenance section in manual. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 31...
  • Page 31 We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,...

  • Page 32: Wiring Diagram (115 Vac)

    115 VAC, 60 Hz POWER SOURCE WHITE WHITE BLACK YELLOW BLACK WHITE NEUTRAL GREEN GROUND CONNECT GREEN WIRE TO SCREW AT ON/OFF SWITCH BOX PAGE 32 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 33: Wiring Diagram (230 Vac)

    SINGLE-PHASE MOTOR 230 VAC, 60 Hz POWER SOURCE WHITE BLACK BLACK YELLOW GREEN (GND). GROUND CONNECT GREEN WIRE TO SCREW AT ON/OFF SWITCH BOX J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 33...

  • Page 34: Explanation Of Code In Remarks Column

    “Remarks” Column. assembly/kit that can be purchased, or is not available for sale through Multiquip. PAGE 34 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 35: Suggested Spare Parts

    2....20111 ....BOTTLE, SYNTHETIC OIL, 22 OZ. NOTICE Part numbers on this Suggested Spare Parts list may supersede/replace the part numbers shown in the following parts lists. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 35...

  • Page 36: Nameplate And Decals

    SERIAL NO. COUNTER CLOCKWISE LIFTING POINT LIFTING POINT CUT DECAL SHEET AS REQUIRED. LUBRICATION LUBRICATION LUBRICATION LUBRICATION DECAL SHEET INTL STDS ISO P/N 11246 PAGE 36 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 37 21302 DECAL: WARNING, KEEP HANDS CLEAR 1848 DECAL: V-BELT COVER NAMEPLATE ............1....CONTACT DISCOUNT- ....................EQUIPMENT 35137 DECAL: WARNING, READ MANUAL 11246 DECAL: SET, INTERNATIONAL STDS. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 37...
  • Page 38 CONTROL AND HANDLE ASSY. NOTES: ITEM 25 INCLUDES ALL ITEMS REFERENCED ON THIS PAGE AND ITEM 16 ON THE SWITCH AND CONDUIT ASSY. INCLUDED WITH ITEM 1. PAGE 38 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 39 HANDLE, ELECTRIC FINISHER ASSY.....1....INCLUDES ITEMS W/@ NOTICE ITEM 25 INCLUDES ALL ITEMS REFERENCED ON THIS PAGE AND ITEM 16 ON THE SWITCH AND CONDUIT ASSY. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 39...
  • Page 40 ON THIS PAGE AND ITEM 25 ON THE CONTROL AND HANDLE ASSY. FOR ELECTRICAL CONNECTIONS REFERENCE OPERATOR’S MANUAL FOR ELECTRICAL WIRING DIAGRAM. CONNECT TO ELECTRIC MOTOR HOUSING. PAGE 40 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 41 HANDLE, ELECTRIC FINISHER ASSY.....1....INCLUDES ITEMS W/@ NOTICE ITEM 16 INCLUDES ALL ITEMS REFERENCED ON THIS PAGE AND ITEM 25 ON THE CONTROL AND HANDLE ASSY. J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 41...
  • Page 42 GUARD RING ASSY. GEARBOX PAGE 42 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 43 PLATE, FRONT MOUNT 0166 A WASHER, LOCK, 3/8" MED 9154 SCREW, HHCS 3/8-16 X 1-3/4" 1946 PLATE, REAR MOUNT 1816 PLATE 2274 STATIONARY GUARD RING J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 43...
  • Page 44 ITEMS 1,4, 25, AND 29 PLUS GASKETS. BEARING KIT INCLUDES ITEMS 6,7,18 AND 19. GEARBOX ASSEMBLY ITEM 30, INCLUDES ITEMS WITHIN DASHED LINE EXCEPT ITEMS 12,13 AND 31 PAGE 44 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 45 BOTTLE, SYNTHETIC OIL, 22 OZ. (650 ML) 2 10136 WASHER, FLAT SAE 3/8" 0683 PIN, COTTER 3/32" D X 3/4" L. 1150 YOKE ARM 1151 PIN, YOKE ARM J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 45...

  • Page 46: Spider Assembly

    3 INCLUDED WITH ITEM 19 OR CAN BE ORDERED SEPARATELY (P/N 1471) TORQUE TO 90 FT.-LBS (122 Nm) TORQUE TO 130 FT.-LBS (176 Nm) PAGE 46 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)

  • Page 47: Blade Assembly

    SCREW, HHCS 5/16-18 X 1-3/4" 23647 KIT, BOLT SAE BLADE ........1....INCLUDES ITEMS W/@ BLADE ASSEMBLY ...........4....CONTACT DISCOUNT- ....................EQUIPMENT 1817 TOOL, TROWEL ARM ADJUST. FIXTURE J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 47...
  • Page 48 ELECTRIC MOTOR ASSY. PAGE 48 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 49 PULLEY, DRIVEN, 40-TBR X 3/4" 1867 PLUG,ELEC MOTOR, 5/8 X .90 1923 GUARD, BELT 0181 B WASHER, LOCK 1/4" MEDIUM 0131 A SCREW, HHC 1/4-20 X 3/4" J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 49...
  • Page 50 BLADE ASSY. BOLT KIT PAGE 50 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15)
  • Page 51 SNAP PIN 1/4" X 1-3/4" ........8....CONTACT DISCOUNT-EQUIPMENT 1434 TROWEL LUG (FINISH BLADE ONLY) 0202 SCREW, HHCS 5/16-18 X 1" RING 0201 GUARD RING LUG J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 51...
