Wiring Diagram (230 Vac) - MULTIQUIP J36E2 Operation And Parts Manual

MOTOR CONTROL/
OPERATOR PRESENCE LEVER
MICRO-SWITCH
C NC
NO
RED
GREEN
BLACK
BLACK
WHITE
X Y
L6-20P
GREEN
SINGLE-PHASE
230 VAC, 60 Hz
POWER SOURCE
BLACK
L1
RED
L2
GREEN (GND).
GROUND
J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 33
BLACK
RED
GND
T2
T3 T1
L1
L3
L2
WHITE
WHITE
2-POLE MASTER
ON/OFF SWITCH
BLACK
REAR VIEW
OF CONNECTOR
2-POLE MASTER
ON/OFF SWITCH
T3
L3
NO
COM
T1
L1
NO
COM
CONNECT GREEN
WIRE TO SCREW
AT ON/OFF SWITCH BOX

WIRING DIAGRAM (230 VAC)

POWER CABLE
MICRO-SWITCH
RED BLACK YELLOW/BLACK
NO
WHITE
2HP, 230 VAC
SINGLE-PHASE,
60 Hz MOTOR
LINE LINE
BLACK WHITE
BLACK
YELLOW/
YELLOW
BLACK
BROWN
1
RED
ORANGE
WHITE
A.O. SMITH
NOTE:
TO REVERSE DIRECTION OF
1
SHAFT ROTATION. INTERCHANGE
RED AND BLACK WIRE LEADS
2HP
MOTOR
BLACK
YELLOW
WIRE
NUT
