MULTIQUIP J36E2 Operation And Parts Manual page 41

NO. PART NO.
1#@ 0179
2@# 0178
3@$# 2505
4@#+ 1H404
5@# 0304
6@# 0175 1
7@# 4693
8@# 0174
9@# 0173
10@# 60077
11@# 0176
12#@ 5044 A
13#@ 1268
14@ 60077
15@ 1189
16 1921
NOTICE
ITEM 16 INCLUDES ALL ITEMS REFERENCED ON
THIS PAGE AND ITEM 25 ON THE CONTROL AND
HANDLE ASSY.
J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION AND PARTS MANUAL — REV. #1 (8/27/15) — PAGE 41
PART NAME
CORD CAP 3-WIRE 1Ø (FEMALE)
CORD CAP 3-WIRE 1Ø (MALE) .......................1................INCLUDES ITEMS W/$
PIGTAIL, 15"
ON/OFF SWITCH
SCREW
SWITCH BOX, 1Ø ..............................................1................INCLUDES ITEM W/+
TERMINAL, RING 16-14 #8
FITTING, 3/8" FLEX CONDUIT
FITTING, 3/8" 90° CONDUIT
CONDUIT .375 FLEX, 5.0' L ..............................5................1PC=1FT
FITTING, 3/8" SWITCH BOX TO PIGTAIL
SCREW, FLHP 10-32 X 3/4"
MICRO SWITCH
CONDUIT .375 FLEX, 0.790' L ..........................1................1PC=1FT
SWITCH AND CONDUIT ASSY. ........................1................INCLUDES ITEMS W/#
HANDLE, ELECTRIC FINISHER ASSY. ............1................INCLUDES ITEMS W/@
SWITCH AND CONDUIT ASSY.
QTY.
1
1
1
4
10
3
1
1
3
3
REMARKS
