6.2 Data Tabs

Each device connected to the Data Pro will have its own Data Tab. If the device is a Modbus device
then the tab will show the Modbus map along with the current readings. If an SPS or FIC is connected
to Com 5 then the Data Tab will contain a grid showing the last five reading from the gauge. In the case
of the FIC, where you can have multiple gauges on one FIC, each gauge will have its own Data tab. .
Figure 7 shows the Information displayed on a gauge tab for Gauge "12345678":
1. Gauge Serial Number or Alias Name
2. Gauge readings per user selected units
3. User specified sample rates for gauge data
Data Pro
Operation Manual
1
4
5
7 8
Figure 6 – Peripherials Tab
2
3
9
