  • Page 1 CLR60 CLEAR ICE MACHINE...
  • Page 2 (consisting of the compressor, the condenser, the evaporator, the hot gas bypass valve, the dryer and the connecting tubing) in each U-Line product to be free from defects in materials and workmanship for a period of five years from the date of purchase. During the initial one-year warranty period for all U-Line products U-Line shall: (1) at U-Line’s...

  • Page 3: Introduction

    INTRODUCTION Congratulations on your purchase of a U-Line CLR 60 Ice Maker. A pio- neer in the field for more than 35 years, U-Line is the world’s number one manufacturer of built-in, under-counter ice making and specialty refrigeration products. U-Line dedicates 100% of its research and development to these products.

  • Page 4: Table Of Contents

    User’s Manual If you do not return your Warranty Registration Card, U-Line will use the date of sale to the U-Line distributor as the first date of warranty for your new ice maker. Please also record the purchase date or your U-Line unit and your dealer’s name, address and telephone number.

  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Do not attempt to install or operate your unit until you have read the safety precautions in this section. Safety items throughout this manu- al are labeled with Warning or Caution. Warning means that failure to follow this safety statement may result in extensive product damage, serious personal injury or death.

  • Page 6: Installation Dimensions

    Obstructing free air flow can cause the unit to malfunction, and may void the warran- • Use only genuine U-Line replacement parts. parts can reduce ice rate, cause water to overflow from the ice maker, cause flooding, damage the unit and may void the warranty.

  • Page 7: Drain Installation

    Failure to follow recommendations and instructions may result in damage and/or harm. The CLR60 can be installed using a gravity drain or can use a factory installed or equivalent drain pump. Follow these guidelines when installing drain lines to prevent water from...
  • Page 8 User’s Manual To prevent accidental electrocution, make certain that the floor surfaces surrounding the unit are dry whenever power is removed from, or applied to the unit. 1. Make certain the unit is not plugged into an electrical outlet. Using a screwdriver, carefully push the power cord grommet through the hole in the back panel.

  • Page 9: Connecting A Drain Pump

    CLR60 with factory installed pump, U-Line strongly rec- ommends the use of the U-Line P60 drain pump. If a pump other than the U-Line P60 drain pump is to be used, it must meet the fol- lowing specifications: •...

  • Page 10: Site Preparation

    • Operating temperature range of 50°F to 110°F (10°C to 40°C). In the event of a power outage, restricted drain or pump failure, the failure to use the U-Line P60 drain pump or a pump with the above listed specifications, could result in substantial water leakage and pooling with severe and costly water damage and related conse- quential damages and harm.
  • Page 11 (see REVERSING DOOR). All U-Line units have a zero clearance for the door to open (see Figure 2). 6. Install a 1/4 inch copper water line (not supplied with unit) from the nearest COLD water pipe.

  • Page 12: Connecting The Water Supply

    However, make cer- tain that the tubing is not pinched or damaged during installation. • U-Line specifies the use of copper tubing for installation. Position the unit to allow free air flow through the front grille (see Figure 3).
  • Page 13 4. Locate the compression fit- ting and ferrule packed in the unit. Slide the compression fitting and ferrule over the 1/4 inch water supply line. Do not use thread sealing compound or tape. two wrenches, tighten the compression fitting on the supply line (see Figure 6).

  • Page 14: Leveling The Unit

    User’s Manual After completing the installation, turn on the water and recheck water and drain connection for leaks. Apply addi- tional tightening if needed. Do NOT use thread sealing com- pound or tape. Route the water supply line through the clip on the sidewall of the unit in such a way as to prevent the line from com- ing in contact with any internal components other than the solenoid valve (see Figure 5).

  • Page 15: Grille Installation

    Figure 10 3. Check the levelness after each adjustment and repeat the previous steps until the unit is level. GRILLE INSTALLATION 1. With a standard blade screwdriver (or 1/4" nutdriver), remove the screw needed to attach the grille (see Figure 12). 2.

  • Page 16: Reversing The Door

    User’s Manual 3. Place hook-hinges (locat- ed on the rear bottom side of the grille) on the front unit base. Swing the grille up into posi- tion, aligning the grille and cabinet screw holes (see Figure 13). 4. Insert the screw, being careful not to over tighten.
  • Page 17 3. Lift the door off the bottom hinge. 4. Remove bottom hinge from cabinet (2 screws) (see Figure 16). Remove screws on opposite side of cabinet (see Figure 17). Note that there may be a nut behind one or both screws on either side.
  • Page 18 User’s Manual RIGHT SIDE DOOR SWING RIGHT SIDE HINGE 8. Remove pivot screw from top hinge, invert screw and reinstall pivot screw in top hinge (see Figure 20). 9. Remove three plastic plugs in hinge holes, top of cabinet, opposite side. Be careful not scratch cabinet Figure 21).

  • Page 19: Aligning The Door

    CUSTOM DOOR PANEL INSERT A custom door panel insert can be installed in your U-Line unit. The door will accept a flat or raised panel. The maximum panel thickness where inserted into the door reveal (channel) is 1/4" thick. For raised panels, the depth of the reveal is 1/4"...
  • Page 20 User’s Manual Custom Door Panel Dimensions Model CLR 60 28-5/32" CLR 60SS 29-13/32" SS - Stainless steel units Install the insert as follows: WARNING Insert edges may be SHARP! Use care when installing. 1. Remove top hinge screw pin (large Phillips head, see Figure 23).

  • Page 21: Built-In Installation

    Figure 25 BUILT-IN INSTALLATION Your U-Line product has been designed for either free-standing or built- in installation. When built-in, your U-Line product does not require addi- tional air space for top, sides or rear. However, the front grille must NOT be obstructed.

  • Page 22: Initial Start-Up

    User’s Manual INITIAL START-UP Once installation and leveling is complete, the unit is ready for initial start-up and operation. 1. Plug the appliance cord into a 115V polarized and grounded elec- trical outlet. 2. Open the water supply valve in the main water source. 3.

  • Page 23: Normal Operation

    NOTE The cycle selector switch is recessed behind the front grille. An opening is pro- vided in the grille to access the switch (see Figure 27). NORMAL OPERATION The ice maker is designed to make clear ice from most water sources on a consistent basis.

  • Page 24: Adjusting Ice Thickness

    User’s Manual ADJUSTING ICE THICKNESS The ice thickness control is set to automatically maintain an ice bridge of 0.16-0.32 cm (1/16- 1/8 inch) thick. A dimple in each cube is normal (see Figure 28). If an adjustment is needed, per- form the following steps: Do not touch electrical wires.

  • Page 25: Care And Cleaning

    Ice thickness adjustment dial should be turned only one increment at a time. Allow unit to stabilize for 24 hours before making further adjustments. 4. Turn ice thickness adjustment dial clockwise for a thicker ice bridge or counterclockwise for a thinner ice bridge. 5.
  • Page 26 User’s Manual INLET SCREEN CLEANING The solenoid valve inlet screen must be cleaned at least once each year as follows: 1. Shut off the water at the water supply valve. 2. Remove front access panel to expose water solenoid valve. 3.
  • Page 27 Use only U-Line Ice Machine Cleaner (part number 41978). It is a violation of Federal law to use this solution in a man- ner inconsistent with its labeling. Use of any other cleaner can ruin the finish of the evaporator and will void the war- ranty.
  • Page 28 User’s Manual 7. When water begins to flow over the evaporator (approxi- mately 3 minutes), add one package U-Line Machine cleaner water reservoir. 8. Reinstall inside front cover. 9. When self-cleaning process stops (approximate- ly 45 minutes) it may be...

  • Page 29: Storage, Vacation And Moving

    STORAGE, VACATION AND MOVING If the unit is to be stored, moved or not used for extended periods, it will be necessary to drain the system of water. Electrical Shock Hazard. before servicing. Before operating replace all panels. Failure to do so can result in death or electrical shock.

  • Page 30: Troubleshooting

    User’s Manual TROUBLESHOOTING BEFORE CALLING FOR SERVICE If the unit appears to be malfunctioning, read through NORMAL OPER- ATION first. If the problem persists, check the TROUBLESHOOTING GUIDE. Locate the problem in the guide and refer to the cause and its remedy before calling for service.
  • Page 31 Problem Unit runs but Inadequate airflow at produces very the front of the unit little ice Ice thickness (continued) adjustment dial improperly set Ice is slow to Ice-making system release or does is dirty not release from the evaporator Unit is not level Low air temperature around unit Poor ice quality...

  • Page 32: If Service Is Required

    Obstructed drain full of water REPLACEMENT PARTS: Use only genuine U-Line replacement parts. The use of non U-Line parts can reduce ice rate, cause water to overflow from ice maker mold, damage the unit, and may void the warranty. IF SERVICE IS REQUIRED If the need for service arises, contact the dealer from whom the unit was purchased.
  • Page 33 Notes ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________...
  • Page 34 User’s Manual Notes ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________ ___________________________________...
  • Page 36 P .O. Box 245040 Milwaukee, WI 53224-9540 Phone 414.354.0300 FAX 414.354.7905 Printed in U.S.A. P/N 41952...
