- Page 1 Installation Guide CLR2160 — Clear Ice Maker ® CLRCO2175 Combo — Clear Ice Maker/Refrigerator www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2007 U-Line Corporation 05/2007...
-
Page 2: Table Of Contents
Danger, Warning or Caution based on the risk type: Installation of the CLR2160 ..... . 21 Installation of the CLRCO2175 ....21 DANGER Relocating the Shelves (CLRCO2175) . - Page 3 2 Inspect and Plan Use this appliance for its intended purpose only and follow these general precautions along with those listed You have received a carton containing your CLR2160 Ice throughout this guide: Maker or CLRCO2175 Clear Ice Maker/Refrigerator with...
-
Page 4: Exterior Cleaning
Note: If cleaning with mild detergent and warm water Stainless Steel Polish and Cleaner, which can be solution and soft cloth, the unit MUST be treated with purchased from U-Line Corporation. (The part number Claire Stainless Steel Polish and Cleaner or comparable is 173348.) Comparable products are acceptable. -
Page 5: Cut-Out Dimensions Clr2160
CLR2160/CLRCO2175 Ice Makers Product Dimensions CLR2160 3 Prepare Site 26-1/8" 24" Your U-Line product has been designed for either free- Including Including Handle Handle standing or built-in installation. When built-in, your unit does not require additional air space for top, sides or rear. -
Page 6: Cut-Out Dimensions Clrco2175
CLR2160/CLRCO2175 Ice Makers Cut-Out Dimensions CLRCO2175 Product Dimensions CLRCO2175 24" 26-1/8" Including Including Handle Handle 34-1/8" 34-1/8" See Electrical Specifications 24" for Power Supply 34-1/4" 35-1/8" 23-15/16" 23-15/16" 8" Black and White Stainless Steel Figure 5 24-3/16" Figure 4 Please note that the unit has adjustable feet that can add one additional inch to height during leveling or to match Follow the cut-out drawing in Figure 4. -
Page 7: Other Side (See Figure
CLR2160/CLRCO2175 Ice Makers Reversing the Door 4. Remove the two door closer inserts from the existing bottom hinge and install as shown on the new bottom (Black and White Units Only) hinge (see Figure 11). All U-Line units (except Stainless Steel models) may be left- or right-hand opening. -
Page 8: Other Site Requirements
For more information see Page 15. For example: Drain Placing a CLR2160 Clear Ice Maker next to a 2115 series The unit’s generous 7-inch drain connection height unit would require a cut-out width of: extends the distance the unit can be located from a 15-3/16"... -
Page 9: Figure
Electrical Specifications. Custom 1/4" Dimensions: Width: 23-1/32" Typical Side-By-Side Cut-Out Height: 27-11/16" For 2115 & CLR2160 models cut the panel insert to the following dimensions. Custom 1/4" Dimensions: Preferred Width: 14-1/32" Location for Acceptable... -
Page 10: Full Overlay Door Panel
Full Overlay Door Panel Door Panel Preparation A full overlay door panel completely covers the doorframe and handle to give a built-in appearance. See your U-Line dealer for the optional Full Overlay Door Panel Kit. 2175 Models: P/N U-OL2175B -- Black... - Page 11 CLR2160/CLRCO2175 Ice Makers 2. Create a relief (Figure 19) for pivot plate by cutting Installation Instructions notch in top corner of overlay panel. Refer to Figure Removing Existing Door 20 for exact specifications. 1. Remove the door shelves by first pulling shelves up at a 45°...
-
Page 12: Figure
15-9/16" ± 1/4" 7 Places Model 2175 Existing Bottom Pivot Plate Existing Bottom Pivot Plate, Flush Side Facing Out) 6 places Model 2115 and CLR2160 (Remove and Discard) #8-32 x 3/8" SEMS Hex Screw For use with #10 x 5/8" Two Places... -
Page 13: Figure
CLR2160/CLRCO2175 Ice Makers 4. Attach Top Pivot Plate to door handle, on side where hinges will be. Use the two #8-32 x 1/2" Flat Head Phillips screws (Black) supplied with kit (see Figure 28). #8-32 x 1/2" Flat Head Screws... -
Page 14: Checking Door Alignment
CLR2160/CLRCO2175 Ice Makers 5 Adjust Door Checking Door Alignment The unit’s door is aligned at the factory before shipment. Slotted However, its alignment could have been disturbed during Mounting Notch shipment or during door panel installation. Holes IMPORTANT Properly aligned, the door should be 1/8" below the top of the unit’s cabinet, NOT flush with the top (see Figure 31). -
Page 15: Water Supply Connection
The CLR2160 or CLRCO2175 can be installed using a To connect to water supply: Gravity Drain, a Factory-Installed Drain Pump (U-Line P60) or a Locally-Installed (U-Line P60) Drain Pump. - Page 16 Gravity Drain, you may have ordered the CLR2160 or CLRCO2175 with a U-Line P60 Drain Pump. See Figures 42, 43 and 44 for typical installations requiring a Drain Pump. If you need to install a P60 Drain Pump into your unit, see Locally-Installed Drain Pump on Page 17.
- Page 17 In the event of a power outage, restricted drain or pump Figure 41 ULIN_0575_A failure, the failure to use the U-Line P60 drain pump or a pump with the above listed specifications, could result in substantial water leakage and pooling with severe and costly water damage and related consequential damages and harm.
-
Page 18: Final Water/Drain Connection
CLR2160/CLRCO2175 Ice Makers Stand Pipe 9/16" Wrench P60 Pump Required 1/4" Copper Water Supply Line Waste Shut-Off Valve 7/16" Wrench Cold Water Water From Water Supply to Ice Maker Figure 45 Waste Figure 42 ULIN_S_0168_A ULIN_0571a_A To connect to drain: Disposal Assembly 1. - Page 19 CLR2160/CLRCO2175 Ice Makers 3. Attach the copper water line to the back of the unit 13. If any issues are found, retrace the drain connection, using the supplied clamp and the back panel screw (see correct the issue and retest with water.
-
Page 20: Electrical Specifications
1. Use a level to check the Plugging the unit into a receptacle located behind an levelness of the ice maker adjacent cabinet will allow the CLR2160 or CLRCO2175 to from front to back and be more easily serviced with self-diagnostics without from side to side. -
Page 21: Installation Tip
2. If the ice maker is not level, adjust the feet on the 9 Install the Unit corners of the unit as necessary (see Figure 50). Installation of the CLR2160 1. Open the water supply valve in the main water source. 2. Plug in the power cord. -
Page 22: Relocating The Shelves (Clrco2175)
CLR2160/CLRCO2175 Ice Makers Relocating the Shelves (CLRCO2175) Installation Troubleshooting Both the glass shelves in the refrigerator and the inner Problem door shelves can be moved to accommodate your bottles, cans and containers. Water is leaking under the unit. Glass Shelves on Right-Hand Hinge Units Solution 1. -
Page 23: Initial Start-Up
The CLRCO2175 display (see Figure 53, 3) will show the set-point temperature (38°F) when the unit is on and will show OFF when the unit is off. The CLR2160 display (see Figure 53, 3) will show ICE when the unit is on and will show OFF when the unit is off. -
Page 24: Start-Up Troubleshooting
See the Use and Care Guide’s Troubleshooting Guide for more solutions. For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in undercounter icemakers, Combo ®...
