- Page 1 Installation Guide CLR2160 — Clear Ice Maker www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2006 U-Line Corporation 08/2006...
-
Page 2: Table Of Contents
Installation Tip ....... . 17 Installation of the CLR2160 ..... . 18 Installation Troubleshooting . - Page 3 08/2006 CLR2160 — Clear Ice Maker 2 Inspect and Plan You have received a carton containing your CLR2160 Clear Ice Maker with a package inside containing a Use and Care Guide, a Product Registration Card and water connection parts. Complete and mail the Product Registration Card or register online at www.U-LineService.com.
-
Page 4: Exterior Cleaning
CLR2160 — Clear Ice Maker 3 Prepare Site Your U-Line product has been designed for either free- standing or built-in installation. When built-in, your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for water, drain and electrical connections in the rear. -
Page 5: Product Dimensions
90° Door Swing Door Swing Black and White Figure 3 08/2006 CLR2160 — Clear Ice Maker Reversing the Door (Black and White Units Only) All U-Line units (except Stainless Steel models) may be left- or right-hand opening. The door opening is... -
Page 6: Other Site Requirements
Drain can NOT be located directly below unit. Unit has a solid base that will not allow unit to drain below itself. Environmental Requirements Many U-Line models are designed to operate in harsh outdoor/marine environments. Special considerations include the following: •... -
Page 7: Side-By-Side Installation Instructions
Cut-Out Dimensions in each unit’s Installation Guide. For example: Placing a CLR2160 Clear Ice Maker next to a 2115 series unit would require a cut-out width of: 15-3/16" + 15-3/16" = 30-3/8" Placing a CLR2160 Clear Ice Maker next to a 2175 series unit would require a cut-out width of: 15-3/16"... -
Page 8: Full Overlay Door Panel
Door Panel Preparation A full overlay door panel completely covers the door frame and handle to give a built-in appearance. See your U-Line dealer for the optional Full Overlay Door Panel Kit. 2175 Models: P/N U-OL2175B -- Black P/N U-OL2175W -- White 2115 &... - Page 9 It is important to ensure that all drilled holes are drilled to the correct depth in order to avoid splits in the wood when hardware is installed. 08/2006 CLR2160 — Clear Ice Maker Installation Instructions Removing Existing Door 1. Remove the door shelves by first pulling shelves up at a 45°...
- Page 10 Wood Panel 3/8" Figure 19 Both Sides Drill ø 5/32" x 3/8" Deep 7 Places Model 2175 6 places Model 2115 and CLR2160 For use with #10 x 5/8" Wood Screw and Nylon Spacer 1" 11-7/8±1/32 For use on Model 2175 Only Figure 20 3.
- Page 11 4. Replace the door closure assembly onto the bottom pivot post (see Figure 26). Be sure that bosses on closers align with holes in hinge and hinge plate. 08/2006 CLR2160 — Clear Ice Maker Door Closure Top Top Pivot Plate Screw to attach Handle...
-
Page 12: Checking Door Alignment
2. With door upside-down, loosen but do not remove the two screws on the door’s bottom hinge plate. Figure 28 www.U-LineService.com CLR2160 — Clear Ice Maker Slotted Mounting Holes Raise Outside Door Edge Figure 29 3. -
Page 13: Drain Connection
Drain can NOT be located directly below unit. Unit has a solid base that will not allow unit to drain below itself. The CLR2160 can be installed using a Gravity Drain, a Factory-Installed Drain Pump (U-Line P60) or a Locally- Installed (U-Line P60) Drain Pump. - Page 14 Figure 35 IMPORTANT Before installing your U-Line CLR2160 with Factory- Installed U-Line P60 Pump, it is extremely important to check and test all hose connections at the drain pump. There is a possibility that hose connections may have loosened during shipment.
-
Page 15: Water Supply Connection
CLR2160 — Clear Ice Maker In the event of a power outage, restricted drain or pump failure, the failure to use the U-Line P60 drain pump or a pump with the above listed specifications, could result in substantial water leakage and pooling with severe and costly water damage and related consequential damages and harm. -
Page 16: Electrical Specifications
See Figure 42 for recommended receptacle location. Plugging the unit into a receptacle located behind an adjacent cabinet will allow the CLR2160 to be more easily serviced with self-diagnostics without disturbing your installation. Preferred... -
Page 17: Leveling Information
(see Figure 44). Figure 44 08/2006 CLR2160 — Clear Ice Maker 2. If the ice maker is not level, adjust the feet on the corners of the unit as necessary (see Figure 45). Figure 45 3. -
Page 18: Installation Of The Clr2160
6. Test the drain system by pouring one gallon of water into the ice bin. The water should drain freely and there should be no leakage. www.U-LineService.com CLR2160 — Clear Ice Maker Installation Troubleshooting Problem Water is leaking under the unit. -
Page 19: Initial Start-Up
All settings are factory preset. No adjustments should be necessary at this time. For information about Ice Cube Thickness, see the Use and Care Guide. 08/2006 CLR2160 — Clear Ice Maker Start-Up Troubleshooting Problem Unit does not appear to turn on when Power icon is pressed. -
Page 20: Service Information
