- Page 1 Operating Instructions for the Range SUB-BASS SYSTEMS REL Acoustics Limited North Road, Bridgend industrial Estate Bridgend, CF31 3TP United Kingdom Telephone: +44 (0)1 656 768 777 Fax: +44 (0) 1 656 766 093 www.REL.net Web:...
- Page 2 REL Acoustics ‘Q’ range User manual First Printed March 12 2003...
-
Page 3: Table Of Contents
REL Acoustics ‘Q’ range User manual Contents CONTENTS................................. 3 IMPORTANT SAFEGUARDS ..........................4 WARNING................................... 4 WELCOME ................................. 5 WORLD WIDE WARRANTY ..........................5 SERVICE AFTER WARRANTY........................... 5 DESIGN SAFETY ..............................6 IMPORTANT................................6 INTRODUCTION TO ‘Q’ RANGE SUB BASS SYSTEMS ................7 CONTROLS AND CONNECTIONS - QUAKE.................... -
Page 4: Important Safeguards
REL Acoustics ‘Q’ range User manual IMPORTANT SAFEGUARDS 1. Read all of these instructions. 2. Save these instructions for future use. 3. Unplug from the wall socket before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. -
Page 5: Welcome
REL Acoustics ‘Q’ range User manual WELCOME Thank you for buying a REL “Q” range Sub-Bass system. Our “Q” range is carefully hand built using the finest materials available and is designed for maximum performance. This manual contains important safety information as well as helpful advice and should be carefully studied before connecting up. -
Page 6: Design Safety
REL Acoustics ‘Q’ range User manual DESIGN SAFETY This apparatus is designed to Class II specification and is double insulated, therefore it does not require to be earthed. This apparatus is supplied with a fitted mains plug. For UK operation a 5 Amp fuse is fitted in the plug. -
Page 7: Introduction To 'Q' Range Sub Bass Systems
REL Acoustics ‘Q’ range User manual Main Features of REL Quake, Q108 (US ONLY), Q150E, Q200E, Q201E and Q400E 1. High level input and low level input. Also PC input on Quake and Q108 2. Separate volume controls for high level and low level inputs 3. -
Page 8: Controls And Connections - Quake
REL Acoustics ‘Q’ range User manual CONTROLS AND CONNECTIONS - QUAKE POWER DEPTH SLAM 41HZ 26HZ 106HZ HI LEVEL CONTOUR ROLLOFF MODE LO LEVEL HI LEVEL QUAKE MODE SELECTOR SOURCE PHASE LINE 100 WATT MOSFET SUB-BASS SPEAKER SYSTEM LINE PROTECTED BY... -
Page 9: Controls And Connections - Q108 Us Market Only
REL Acoustics ‘Q’ range User manual CONTROLS AND CONNECTIONS - Q108 US MARKET ONLY POWER 41HZ 26HZ 106HZ HI LEVEL LO LEVEL PHASE CROSS OVER XOVER HI LEVEL Q108 100 WATT MOSFET SUB-BASS SPEAKER SYSTEM PROTECTED BY ~ 110-120 VAC 50-60 HZ FUSE 3.15 A/T... -
Page 10: Controls And Connections - Q150E
REL Acoustics ‘Q’ range User manual CONTROLS AND CONNECTIONS - Q150E POWER LO LEVEL GROUND HI LEVEL 59HZ 106HZ ROLLOFF 41HZ 26HZ 32HZ MODE SELECTOR SOURCE PHASE LINE MODE LINE 180 deg 180 deg ~ 220-240 VAC 50-60 HZ DEPTH... -
Page 11: Controls And Connections- Q200E, Q201E, Q400E
REL Acoustics ‘Q’ range User manual CONTROLS AND CONNECTIONS- Q200E, Q201E, Q400E POWER LO LEVEL HI LEVEL 59HZ 106HZ ROLLOFF 41HZ 26HZ 32HZ MODE SELECTOR SOURCE PHASE LINE MODE LINE 180 deg 180 deg ~ 220-240 VAC 50-60 HZ LO LEVEL... -
Page 12: Connecting Up
REL Acoustics ‘Q’ range User manual CONNECTING UP Always switch off your system before disconnecting any wires To increase the versatility of connecting up, the “Q” range has two separate inputs. A Neutrik Speakon socket and a pair of phono sockets. (single phono socket on Quake and Q108). As mentioned, this is to facilitate use with both two channel stereo systems and AV surround sound systems. -
Page 13: To Connect To The Power Amplifier Using The Unbalanced Neutrik High Level Input
REL Acoustics ‘Q’ range User manual To connect to the power amplifier using the UNBALANCED Neutrik high level input. To engage the Neutrik Speakon plug, insert fully into socket and rotate clockwise until locked. To remove the Neutrik Speakon plug, grip body of plug, place thumb on chrome lever, move lever backwards rotate plug anti-clockwise (counter-clockwise in the US) quarter turn and withdraw. -
Page 14: To Connect To The Amplifier/Processor Using The Phono To Phono Low Level Interconnect
REL Acoustics ‘Q’ range User manual To connect to the amplifier/processor using the phono to phono low level interconnect Supplied Phono to Phono Interconnect. To sub/LFE output of Amplifier/Processor Sub Low Level Input. (One phono Only on Quake and Q108) Two low level inputs are provided, 0dB and +12dB, One only on Quake and Q108 at +12dB Connect as shown above. -
Page 15: Mode Selector
REL Acoustics ‘Q’ range User manual MODE SELECTOR (NOT APPLICABLE TO Q108) SOURCE PHASE POSITION LINE LINE 180 DEG 180 DEG The mode switch is a dual function control, it can reverse the phase for both high level and low level inputs and it can bypass the internal filter/roll off. -
Page 16: Rel Set-Up Made Simple
REL Acoustics ‘Q’ range User manual REL Set-Up Made Simple REL products are not traditional subwoofers, but true sub-bass systems. A REL is designed to augment the performance of “full range” speaker systems, to provide linear response down to below 12 Hz (Studio III, -6 dB down at 9 Hz). - Page 17 This process simply orients the driver, and port, to most efficiently vent into the room. In some instances there may be little difference, at which point aesthetic concerns may override performance concerns. For Q series, if possible, point the driver directly out of the corner, equidistant from the side walls.
- Page 18 REL Acoustics ‘Q’ range User manual Note: As the Q-series crossover adjustment uses a single variable control, use the closest correlating position to any of the crossover settings noted above for ST series models. Ultimately, as with the click stops of the ST range, simply bring gain and then crossover up until excess output is achieved, then back down a soft-click or two.
-
Page 19: Rel Set-Up Made Simpler
For Q series, use the variable controls in much the same way, slowly turning up both gain and crossover until excess output is realised, then back down a soft-click or two. -
Page 20: Running In
REL Acoustics ‘Q’ range User manual RUNNING IN Care taken over running in will be rewarded by many years of pleasurable use. Both the electronics and the drive unit will benefit from an initial period of carefully controlled use. Possible damage may be sustained by running in the unit at too high a volume setting over an extended period. -
Page 21: Technical
REL Acoustics ‘Q’ range User manual TECHNICAL The ground switch (if fitted) provides a physical mains earth connection to the Sub Bass System if required. When the unit is connected up and switched on, listen for any ‘hum’ from it, if ‘hum’ is present then change the ground switch position from in to out (on to off for US market) or vice versa. -
Page 22: Power Saving Efficiency
REL Acoustics ‘Q’ range User manual POWER SAVING EFFICIENCY All REL Sub-Bass Systems are designed for maximum power efficiency, both when passing a signal through to its resultant output sound into the room and also when silent. REL circuitry is designed for “power starvation” operation under no signal conditions. This means that... -
Page 23: Specifications
Neutrik Speakon Interconnect Not Quake, Q108 Only 10 Metres nominal 5 metre phono interconnect Users manual Spikes Nylon Screws Nylon Feet Grille In the interest of product development, REL Acoustics Limited reserve the right to vary these specifications without notice. -
Page 24: Specifications (Cont.)
5 metre phono interconnect Users manual Spikes Nylon Screws Nylon Feet Q201E – Yes, Q200E - No Grille Q201E – Yes, Q200E - No In the interest of product development, REL Acoustics Limited reserve the right to vary these specifications without notice...
