Front Runner Easy-Out Fitting Instructions

Awning brackets

ENG

Easy-Out Awning

Brackets

RRAC029

30 min

READ ME !

Thank you for purchasing the Easy-Out Awning Bracket.

Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.

Refer to Page 2 for a list of all the components, quantities and tools required.

IMPORTANT WARNING!

IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD

RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT

RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND

DAMAGE. THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO

INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY

FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

RRAC029_REV_C01

Table of Contents

Need help?

Do you have a question about the Easy-Out and is the answer not in the manual?

Page 1 IMPORTANT WARNING! IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT RUNNER PRODUCTS TO YOUR VEHICLE.
Page 2 M8 Nut Cap M8 x 25 Button Head Bolt M8 x 20 Button Head Bolt SLIMLINE II RACK (Steps 2.1 - 2.3) FIGURE 1.1 SLIMLINE RACK (Steps 3.1 - 3.3) FIGURE 1.2 RRAC029_REV_C01 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS...
Page 3 AWNING BRACKET INSTALLATION - SLIMLINE II RACK Choose which side for the Slimline II Tray you'd like to install the Awning. On the chosen side, slide six M8 Nyloc Nuts (Item 8) in the T-slot channel at the corner of the Tray making sure the M8 Nyloc Nut thread is facing upward.
Page 4 Mounting Brackets. Fit Flat Washers and Nyloc Nuts (Items 3,4 or 7, 8) onto each bolt. Fully tighten all fasteners and place Nut Caps over nuts (Either Item 5 or 9). RRAC029_REV_C01 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS...
Page 5 Congratulations! You did it. Take a step back and admire your work! Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions. Please call us if you have any questions about the installation of this product.

Rrac029
