White Kids' Adjustable Study Desk
Instruction Manual
SKU: DESK-V503G
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v503g
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the DESK-V503G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo DESK-V503G

  • Page 1 White Kids' Adjustable Study Desk Instruction Manual SKU: DESK-V503G Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v503g GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
  • Page 3: Tools Needed

    WARNING: CHOKING HAZARD SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED. TOOLS NEEDED Phillips Screwdriver DO NOT EXCEED WEIGHT CAPACITY. 88lbs Failure to do so may result in serious injury. (40kg) ASSEMBLY STEPS STEP 1 Assemble right and left legs (B2, B3) to desktop (B1) using bolts (A1) with washers (A2).
  • Page 4 STEP 2 Attach stabilizer bar (B4) and stabilizer cushions (B5) to legs using bolts (A1) with washers (A2). Tighten all bolts with Allen wrench (A3). B5x2 A2x4 A1x4...
  • Page 5 STEP 3 If needed, adjust feet to sit level.
  • Page 6 STEP 4 Loosen knobs on sides to raise or lower desktop. Tighten knobs to secure desktop position. 0° -4 0° STEP 5 Loosen knobs on legs to allow height adjustment. Tighten knobs to secure desk height.
  • Page 7 Height Adjustment RAISE: Step on the stabilizer bar with one foot and pull up with even motion on both sides of the desk, until it reaches the desired height. LOWER: Step on the support bar with one foot and pull up with even motion on both sides of the desk, until it reaches max height.
  • Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S AVG. RESOLUTION TIME 309-278-5303 (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
