Desk Riser
Instruction Manual
SKU: DESK-V000K Series
DESK-V000K
DESK-V000KA
DESK-V000KF
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v000k
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
DESK-V000KG
DESK-V000KR
DESK-V000KN
DESK-V000KW
DESK-V000KO
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo DESK-V000K Series
Summary of Contents for Vivo DESK-V000K Series
- Page 1 Desk Riser Instruction Manual SKU: DESK-V000K Series DESK-V000K DESK-V000KG DESK-V000KR DESK-V000KA DESK-V000KN DESK-V000KW DESK-V000KF DESK-V000KO Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v000k GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
- Page 3 ASSEMBLY STEPS STEP 1 Apply Pads ( ) to underside of Keyboard Tray (B). Assemble Stopper (C) to Kayboard Tray (B) using ST4.2x12mm Screws (S-A) and a Phillips screwdriver. STEP 2 Install Rubber Feet (E) to the bottom of Desk (A). Remove shipping tie from desk and set right side up on solid surface.
- Page 4 STEP 3 Raise Desk (A) by lifting the handle on the right side of the frame. Place Keyboard Tray (B) on the metal brackets on Desk (A). Secure Keyboard Tray to brackets using M5x10mm Screws (S-B) and tighten with a Phillips screwdriver.
- Page 5 STEP 4 Apply Cable Clips ( ) to underside of Desk (A). Desk riser is now ready for use OPTIONAL Grommet Installation: See Page 6...
- Page 6 GROMMET MOUNT INSTALLATION This desk riser features a pre-drilled grommet hole for installing a monitor mount directly to desk surface. To utilize this feature, your will need to remove the plug from the top surface of the riser. Secure your mount using a grommet mounting method, using the hardware and assembly steps from your monitor mount.
- Page 7 CAUTION! Keep monitor and Follow the cable Leave enough slack Raise desktop laptop base fully on routing instructions to in cable to allow for slowly to keep the desktop. avoid the potential to full range of vertical items stable. pinch cables. motion (15”...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
