- Page 1 Installation Guide PB3000...
-
Page 2: Table Of Contents
PB3000 Installation Guide Contents Chapter 1 Cable Embedding ........................................1 Chapter 2 Cabinet Installation ........................................2 Chapter 3 Boom Installation ........................................3 Chapter 4 Control board introduction ....................................4 Chapter 5 Troubleshoot ..........................................5... -
Page 3: Chapter 1 Cable Embedding
PB3000 Installation Guide Chapter 1 Cable Embedding Prepare φ25 protective sleeve and cable in advance. Route cables to be connected through protective sleeves. Use a tool to open a cable tray on the ground, see figure 1-1. Cabinet Expansion bolt... -
Page 4: Chapter 2 Cabinet Installation
PB3000 Installation Guide Chapter 2 Cabinet Installation Use Bolt Holes Dimensioning to mark the installation position of the cabinet. Drive four expansion bolts into the Bolt Holes Dimensioning, as shown in figure 2-1. Open the access door and install the parking barrier. -
Page 5: Chapter 3 Boom Installation
PB3000 Installation Guide Chapter 3 Boom Installation Take out the booms. Install the booms. (If your purchase is PB3010L/R, there will be only one boom. If your purchase is PB3030L/R or PB 3060L/R there will be a main boom and a vice boom which need to be connected together. See figure 3-1.) -
Page 6: Chapter 4 Control Board Introduction
PB3000 Installation Guide Chapter 4 Control board introduction Interface of the Main Control Board Control board Delete All Transmitter Press K4 setting button until D8 yellow light flashes. Hold on K4, press stop button on control board until D9 red light flashes one time. -
Page 7: Chapter 5 Troubleshoot
PB3000 Installation Guide Chapter 5 Troubleshoot If the boom fails to fall into a level position, adjust position A; if the boom fails to be lifted upright, adjust position B. See Figure 5-1. If the boom shakes during falling or lifting, adjust position C. The shaking that occurs during lifting is caused by the overlarge spring force.
