- Page 1 BGM2000 Series Barrier Gate (APP Version) User Manual User Manual BGM2000 Series Barrier Gate (APP Version) Date: November 2022 Doc Version: 1.0 English P a g e Copyright©2021 ZKTECO CO., LTD. All rights reserved.
- Page 2 BGM2000 Series Barrier Gate (APP Version) User Manual About the Manual This manual introduces the operations of BGM2000 Series Barrier Gate (APP Version). All figures displayed are for illustration purposes only. Figures in this manual may not be exactly consistent with the actual products.
- Page 3 BGM2000 Series Barrier Gate (APP Version) User Manual Document Conventions Conventions used in this manual are listed below: GUI Conventions For Software Convention Description Bold font Used to identify software interface names e.g., OK, Confirm, Cancel. Multi-level menus are separated by these brackets. For example, File > Create >...
-
Page 4: Table Of Contents
BGM2000 Series Barrier Gate (APP Version) User Manual Table of Contents OVERVIEW ............................5 FEATURES AND FUNCTIONALITIES ....................5 SPECIFICATIONS ..........................6 APPEARANCE AND DIMENSIONS ...................... 7 LEFT AND RIGHT DIRECTIONS ......................7 INSTALLATION PROCEDURE ......................8 ........................8 NSTALLATION RECAUTIONS .......................... - Page 5 BGM2000 Series Barrier Gate (APP Version) User Manual ..................26 IRECTION NTERCHANGE OF THE ........................... 26 PRING DJUSTMENT PRODUCT PACKING LIST ......................27 TROUBLESHOOTING ......................... 28 SAFETY PRECAUTIONS ......................30 TRANSPORTATION AND STORAGE ..................30 WARRANTY ..........................30...
-
Page 6: Overview
User Manual Overview BGM2000 series barrier gate adopts an elegant chassis design with a programmable control board and a high-efficiency brushless DC motor. The built-in LED lights which indicates the on and off mode of barrier gates, suitable for large parking lot. An aluminum foam straight barrier enhances anti-collision ability and wind resistance. -
Page 7: Specifications
BGM2000 Series Barrier Gate (APP Version) User Manual Specifications Model BGM2000L/R Operating Speed 0.6s~3s Boom Arm Length L≤4m Boom Arm Type Round straight boom Chassis Dimension (L*W*H) 350*306*1020mm Chassis Weight 45kg Motor Type 24V DC brushless motor Motor MCBF 5 million times... -
Page 8: Appearance And Dimensions
BGM2000 Series Barrier Gate (APP Version) User Manual Appearance and Dimensions Left and Right Directions The chassis on the left, The chassis on the right, the boom on the right. the boom on the left. -
Page 9: Installation Procedure
BGM2000 Series Barrier Gate (APP Version) User Manual Installation Procedure Installation Precautions • Install the parking barrier on a flattened ground. A cement foundation is required before installation if the ground is not solid and flat. • It is possible to reduce the length of the boom arm, but it cannot be increased. After the boom arm has been cut, it is important to set the spring balance again to achieve a new balance. - Page 10 BGM2000 Series Barrier Gate (APP Version) User Manual Note: • Before the barrier is powered on to run the test process, be sure to install the barrier boom arm of the corresponding length for the test. If the barrier boom arm is not installed, please adjust and remove the spring under the guidance of a professional.
-
Page 11: Mainboard Wiring Instructions
BGM2000 Series Barrier Gate (APP Version) User Manual Mainboard Wiring Instructions • Please disconnect the power supply before wiring. • Check carefully whether the terminals are tightened and whether the wiring is firm. Wire Connection of the New Mainboard Wiring diagram of new control board of the app version:... -
Page 12: Connection With Lpr Camera
BGM2000 Series Barrier Gate (APP Version) User Manual Connection with LPR Camera BGM2000 BGM2000 Confirm Barrier Gate Connection with LPR Device Installtion Based on the project site planning, confirm the installation positions of exits and entrances, and then install the wiring. -
Page 13: Connection With Uhf System
BGM2000 Series Barrier Gate (APP Version) User Manual Connection with UHF System BGM2000 BGM2000 Note: The Reader1 and 2 of Inbio260 Controller corresponds to LOCK1, Reader3 and 4 corresponds to LOCK2. Confirm Barrier Gate Connection with UHF Device Installtion ... -
Page 14: Connection With Loop Detector
BGM2000 Series Barrier Gate (APP Version) User Manual Connection with Loop Detector Anti-smash and Auto-close Function BGM2000 BGM2000 Coil Circumference Coil Number Based on requirements, ensure that the inductance is between 100μH and 200μH. 3m to 6m 5 to 6 turns... -
Page 15: Connection With Vr10 Radar Sensor
BGM2000 Series Barrier Gate (APP Version) User Manual Connection with VR10 Radar Sensor Anti-smash and Auto-close Function BGM2000 BGM2000 Confirm Radar Mounting Holes The installation hole of the radar is between 200 to 300mm from the inside of the straight boom and 650 to 800mm from the driveway ground (non-cement pier);... -
Page 16: Connection With Infrared/Photocell Detector
BGM2000 Series Barrier Gate (APP Version) User Manual Connection with Infrared/Photocell Detector Anti-smash Function BGM2000 BGM2000 Anti-smash and Auto-close Function BGM2000 BGM2000 Confirm Photocell Detector Installtion Note that the transmitter and receiver are install at the same parallel angles. -
Page 17: Connection With Device W I -Fi
BGM2000 Series Barrier Gate (APP Version) User Manual Connection with Device’s Wi-FI The Wi-Fi function is automatically turned on after the device is powered , and the phone can also be connected to the Wi-Fi hotspot of the device after setting the function and parameters of the device through the ZKbarrier APP. - Page 18 BGM2000 Series Barrier Gate (APP Version) User Manual After successful connection, you can implement some functions and parameter settings on the APP according to the actual installation of the equipment in the field.
-
Page 19: Functional Parameter Settings
BGM2000 Series Barrier Gate (APP Version) User Manual Functional Parameter Settings After the initial installation, and first power-on, you must use the "Open" and "Close" buttons on the mainboard to complete the self-check process and learn the description of the menu. -
Page 20: Parameter Settings Description
BGM2000 Series Barrier Gate (APP Version) User Manual Parameter Settings Description （ （ （ （ Ites Description ） ） ） ） Display Mode 01E000: Displays current position of the swing arm 01E001: Controls input signal 01E002: Test mode (the digital LED ... - Page 21 BGM2000 Series Barrier Gate (APP Version) User Manual Boom Arm Closing Speed 05E000: Low 05E001: Medium 05EXXX 05E003 05E003 05E003 05E001 05E002: Fast 05E003: Very Fast Adjust the corresponding speed according to the boom arm length.
- Page 22 BGM2000 Series Barrier Gate (APP Version) User Manual Core Component Position 13E000 13E000 13E000 13E000 13EXXX 13E000: Right 13E001 13E001 13E001 13E001 13E001: Left Reset 14E000: -Normal 14E001: Reset Select [14E001] will restore the default 14EXXX...
-
Page 23: Error Code
BGM2000 Series Barrier Gate (APP Version) User Manual Power-off Open Mode 21EXXX 21E000: Disable 21E001 21E001 21E001 21E001 21E001: Enable Open/Close Limit LED State 22E000: Open limit green light breathing, Close limit light breathing 22EXXX 22E000 22E000... -
Page 24: Remote Control Pairing And Unpairing (Support Setting On The Zkb Arrier App)
BGM2000 Series Barrier Gate (APP Version) User Manual Remote Control Pairing and Unpairing(Support setting on the ZKBarrier APP) 8.4.1 Pairing Long press [Menu/save], then press [Stop/▼] flip down to [15EXXX]. Press [+/-] to set the parameter value. At this time, the LED display value is "15EX0X", and then press any button on the remote control until you hear a beep sound from the Mainboard, it means the pairing is successful, and then press [Menu/save] exit the menu. -
Page 25: Boom Arm Adjustments
BGM2000 Series Barrier Gate (APP Version) User Manual Boom Arm Adjustments Dimensions Horizontal and Vertical Angle Adjustment of Boom Arm (Mechanical Adjustment) Note: The horizontal and vertical angles of the boom arm have been adjusted before leaving the factory. Please do not adjust them without the guidance of professionals to avoid mechanical damage. - Page 26 BGM2000 Series Barrier Gate (APP Version) User Manual this position horizontally. If the boom arm is not level or inclined at this time, unscrew the two rocker (spindle connecting arm) screws, turn the boom arm to the level, and tighten the screws.
-
Page 27: Direction Interchange Of The Boom Arm
BGM2000 Series Barrier Gate (APP Version) User Manual Direction Interchange of the Boom Arm The operation steps are as follows: Before operation, please turn off the power. Remove the spring, spring hanging arm and boom. L to R: replace rocker B; R to L: replace rocker A. -
Page 28: Product Packing List
BGM2000 Series Barrier Gate (APP Version) User Manual Note: When the barrier boom is at 45°, it is the best balance. The spring wire diameter is adapted to different boom lengths. Boom length Spring size and quantity Spring Color logo 1.5m... -
Page 29: Troubleshooting
BGM2000 Series Barrier Gate (APP Version) User Manual Troubleshooting Description: The Power Supply has a 24V output, but the mainboard power indicator does not light up. Cause: 24V output wiring might be reversed. The mainboard might work abnormally. Loose wiring. - Page 30 BGM2000 Series Barrier Gate (APP Version) User Manual Description: The remote-control buttons do not respond. Cause: The remote-control battery is completely discharged. There must be a signal interference with the same frequency and there might be some obstacles too nearby.
-
Page 31: Safety Precautions
BGM2000 Series Barrier Gate (APP Version) User Manual Safety Precautions • It is strictly forbidden to hit the product with hard objects. • When using, please handle with care to avoid strong collision with hard objects. • Do not spill water or corrosive liquids on the surface of the product.
