mTS1000 Series Tripod Turnstile

User Manual

Mars-S100 Series

Applicable Model(s): Mars-100, Mars-S120

Date: July 2023

Doc Version: 1.2

English

Thank you for choosing our product. Please read the instructions carefully

before operation. Follow these instructions to ensure that the product is

functioning properly. The images shown in this manual are for illustrative

purposes only.

P a g e

| 1

For further details, please visit our Company's website

www.zkteco.com.

User Manual

Table of Contents

Need help?

Do you have a question about the Mars-S100 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco Mars-S100 Series

Page 1 Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.zkteco.com. P a g e Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 2 Copyright © 2023 ZKTECO CO., LTD. All rights reserved. Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or "ZKTeco").
Page 3 Mars-S100 Series User Manual relating to the use of the information contained in or referenced by this manual, even if ZKTeco has been advised of the possibility of such damages. This manual and the information contained therein may include technical, other inaccuracies or typographical errors.
Page 4 User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader Door Locks.
Page 5 The information which is significant. Care taken to avoid danger or mistakes. The statement or event that warns of something or that serves as a cautionary example. P a g e Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 6: Table Of Contents
.......................... 37 RROR ODE FOR URNSTILE MAINTENANCE ..........................38 ..........................38 HASSIS AINTENANCE ..........................38 OVEMENT AINTENANCE ........................38 OWER UPPLY AINTENANCE TROUBLESHOOTING.......................... 39 PACKING LIST ............................ 40 P a g e Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 7: Overview
Mars-S100 Series User Manual Overview The Mars-S100 Series speed gates are an elegant and cost-effective entrance control system designed for high-traffic volume. These speed gates are normally held in a locked position, thus denying access to the secured side. Features Long service life, capable of opening and closing the gate more than 5 million times when ...
Page 8: Appearance And System Components
Appearance and System Components 1.2.1 Appearance The appearance and dimensions of the Mars-S100 series are shown in the figure below: P a g e Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 9: System Components
Mars-S100 Series User Manual 1.2.2 System Components The system components of the Mars-S100 series are shown below: 2. Verification units★ 1. Traffic indicator 3. Reserved hole for face device 4. Infrared sensor 5. Barrier 6. Pass through indicator Mechanical System The mechanical system of the turnstile consists of the chassis and the core component.
Page 10: Electronic Control System
If a failure is detected, the system will display relevant error messages on the digital tube, allowing the user to quickly identify and resolve the problem. P a g e | 10 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 11: System Composition
The single-passage management system consists of two single-core speed gates. The multi-passage management system consists of two single-core speed gates and multiple dual-core speed gates. The single-lane management system:  P a g e | 11 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 12: Technical Specifications
Throughput Rate Up to 25 people/min (Using credential) Drive Unit Brushless Motor Infrared Sensor 4 pairs LED Indicator Support Working Environment Indoor Drive Unit Brushless motor P a g e | 12 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 13 762*362*1040(mm) (2 boxes) Net Weight 50kg (±5kg) Gross Weight 64kg (±5kg) Noise ＜60dB Certifications CE and FCC Green: Lane available Traffic Indicator Red: Lane unavailable P a g e | 13 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 14: Function Introduction
It is important to follow the proper guidelines to avoid any recognition issues. Please note that our company will not be liable for any recognition P a g e | 14 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 15: Card Verification
Access Controller. When a user presses their card on the card reading area, the device enters card authentication mode. P a g e | 15 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 16: Qr Code Verification
When the user places the mobile phone displaying the QR code on top of the QR code scanner, the device enters the QR code authentication mode. P a g e | 16 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 17: Facial Verification
Recommended Standing Posture and Facial Expression: Note: Please keep your facial expression and standing posture natural while enrollment or verification. P a g e | 17 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 18 Before installation,please pass the wire through the bracket. Insert the bracket into the hole and fix it with a nut. Adjust the angle of the device. P a g e | 18 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 19: Control System Introduction
Mars-S100 Series User Manual Control System Introduction PGIC10-SV★ Terminal Description Ethernet/POE interface USB Slot Reset Speaker Fire signal Auxiliary output Auxiliary output 12V DC power supply P a g e | 19 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 20 Exit or entry status indicator Door Door Embedded linux operating system. It has a 2.8-inch touch screen (the display screen) where the parameters can be set via touch screen. P a g e | 20 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 21: Master/Slave Motor Driving Controller
MODE: It is used to go back to the previous menu and discard the current operation. ADD: It is used for navigating to the upper menu item and increasing the value. P a g e | 21 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 22 Speaker speed gate Fire power supply for RS232 communication between master and slave drives Infrared sensor receiving port RS485 communication between master and slave drives P a g e | 22 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 23: Ir Board
Power supply for master motor driving controller display IR Board Terminal Description Connecting IR sensor receiving port IR sensor receiving port Firefighting interface speed gate Fire power supply for P a g e | 23 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 24 Mars-S100 Series User Manual Power in Power in Infrared sensor transmitting port Entry indicator Indicator Light Reserved Entry indicator P a g e | 24 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 26: Menu Of Speed Gate
(02E001) Two-way controlled, both need verification (Default).  (02E002) In need verification, out free.  (02E003) In free, out need verification.  (02E004) Two-way free.  P a g e | 26 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 27  (02E006) In prohibited, out need verification.  (02E007) In free, out prohibited.  (02E008) In prohibited, out free.  (02E009) Two-way normally open.  P a g e | 27 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 30 Set the delay time of gate closing after passing. The valid value for gate closing delay time can be set between 0 to 60s and the default value is 0s. P a g e | 30 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 31 (13E004) Slave position  Adjust the position only when Mars-S100 series is installed properly. When setting the zero position, you can manually push the swing arm for fine-tuning. If the barrier exceeds a certain angle, it will be invalid. (At this time, the digital LED displays 13E000).
Page 32 Exchange Entrance and Exit Voice (18EXXX) Ordinary alarm sounds do not need to be exchanged. (18E000) Right in, left out (Default)  (18E001) Right out, left in  P a g e | 32 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 33 Set the angle at which the clutch starts. The larger the number, the bigger the angle. The valid value for Clutch Start Angle can be set between 0 to 99, and the default value is 0. P a g e | 33 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 34 When the Anti-pinch Area Setting needs to be set to (25E001) only, the False Direction Entry (26E000) is effective. (26E000) Close  (26E001) Only alarm (Default)  (26E002) No detection  P a g e | 34 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 35 When the Anti-pinch Area Setting needs to be set to (25E001) only, the Gate Closing Position (28E001) is effective. (28E000) Last pair (Default)  (28E001) Penultimate pair  P a g e | 35 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 36 You can adjust the synchronization of the Slave through this menu, the larger the value, the faster the response of the Slave to open the gate, the setting range lies between 30 to 200, and the default value is 100. P a g e | 36 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 37: Error Code For Turnstile
Power-on Self-test failure, Hall Limit Detection Error ER0004 Run Timeout ER0008 Clutch Locked ER016 The code disk detection failed. ER032 Electric Motor Shaft Lock Protection failure P a g e | 37 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 38: Maintenance
To ensure operational safety, it is important to first switch off the power supply when the speed gate is not in use. P a g e | 38 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 39: Troubleshooting
When the gate is self-tested, the swing obstacles, please remove the obstacles, arm is not in the normal closing restart the self-test after power-on! position! P a g e | 39 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 40: Packing List
Mars-S100 Slave: 1 Mars-S120 Card★ 8 (Mars-S100) Expansion Screw M12*100 4 (Mars-S120) Stainless Steel Maintenance Wipes Hex wrench Allen Screw 8 (Mars-S100) Washer 4 (Mars-S120) P a g e | 40 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
Page 41 Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved. P a g e | 41 Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
