Assembly Instructions
Step 6
Carefully slide the Foot Plate Link Pole (7) into the Main Frame. Connect the two Foot Plates (17) to the
pole with 2 x Foot Plate Bushing (24), 2 x Flat Washer (46) and 2 M8 Nylon Nut (40).
Open the foot straps then place your feet on the Foot Plates (17). Then fasten the straps with the Velcro
tape to keep your feet in place.
8
