Components - Parts

Please check you have all the parts listed below
Note: Some of the smaller components may be pre-fi tted to larger components. Please check carefully
before contacting Argos regarding any missing components.
1.
Main frame x 1
4.
Rowing Arm(L/R) x 2
8.
Hydraulic Cylinder x 2
3
If you have damaged or missing components,
call the
2.
Rear Support Frame x 1
5.
Seat Carriage x 1
10.
Seat x 1
Customer contact number: 0345 600 1714
3.
Main Frame Floor Support(L/R) x 2
6.
Link Pole x 1
17.
Footplate x 2
7.
Footplate Link Pole x 1
21.
Exercise Monitor x 1
