Argos Opti Hydraulic Rower machine Assembly Instructions Manual page 10

Assembly Instructions
4L
8
4R
8
13
Step 7
Slide open the Cover (47) of the Monitor (21) and install two "AA" batteries (not included) in it. Close the
Cover (47) and connect the Sensor Wire (48A) to the Sensor Wire (48B) from the Main Frame.
Turn the Slot Type Adjust Clamps (13) in an anti-clockwise direction to loosen and slide them up and
down the Rowing Arms (4L/R) to adjust the tension of the Hydraulic Cylinders (8). The higher the
position the greater is the tension and vice versa. Once fixed, turn the Clamps (13) in a clockwise
direction to lock them tightly.
9
