Opti Bench with 30KG Weights
Assembly & User Instructions -
–
Important
Please read these instructions fully before assembly or use
These instructions contain important information which will help you get the best from your
equipment and ensure safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6402020
http://www.argos-support.co.uk/
Please keep for future reference
619/3588
Issue 1 -15/10/15
