Note: Extra hardware were provided for attaching the headboard to your Bed Frame (use is optional).
STEP 1:
Line up the Bed Frame (2) board's pre-drilled holes to match those of the Headboard (1) .
Secure the Headboard (1) to the Bed Frame (2) by using 2 pieces of Bolt (B) for the thicker Bed Frame (2), and 2 pieces
of Bolt (A) for the thinner Bed Frame (2).
Before inserting each bolt, place 1 piece of Spring Washer (D) and Flat Washer (C) on each bolt. Then fit 1 piece of Flat
Washer (C) on the bolt as it protrudes through the other side of the Bed Frame (2).
Place 1 piece of Hex Nut (E) after the Flat Washer (C) at the end of each bolt. Then tighten the Bolts (A or B) by
using the Allen Wrench (F).
Repeat the same procedure for each bolt and each side of the Bed Frame (2).
2
A or Bx4 Cx8
STEP 2:
Carefully position the assembled bed to the desired location by four adults.
NOTE: Hardware may loosen over time. Periodically check that all connections are tight.
Customer Service 908-368-1025︱www.modwayfurniture.com
CONNECTING HEADBOARD TO BED FRAME
Dx4
Assembly is completed. The bed is ready to use now!
1
Ex4 Fx1
1
B
C
D
B
F
D C
Hardware & Tool required
C E
2
