MakerBot Replicator
MakerBot Replicator Mini+
MakerBot
Step 1 - Remove Outer Motor
Cover
Grab the Motor Cover and gently
pull away from the Mini. If needed
you can use a small flat head
screw driver, or a tool similar to
it, to make some space between
the Outer and Inner Motor Covers.
Removing the Outer Motor Cover
will expose the screws that attach
the Inner Motor Cover to the
Z-Stage and Spool
Assembly.
Step 2 - Remove Z Carriage
Cover
Grab the Z-Carriage Cover and
slide upward to remove from
Z-stage assembly.
3
