  • Page 1 IMPORTANT Operation Manual...
  • Page 2 Jetball Alley Single GMP Manual WE ARE HERE TO ASSIST For parts and service Have Questions? Contact us! UNIS SERVICE CENTER Tel: 972-241-4263 Email: service@unispartsandservice.com When contacting Service, you will need the following information and the name of your authorized distributor.

  • Page 3: Table Of Contents

    Jetball Alley Single GMP Manual CONTENT IMPORTANT SAFETY INSTRUCTIONS ............... 3 1. SPECIFICATIONS ....................5 2. CONTENTS OF THE ACCESSORY KIT ..............7 3. PART NAME ......................8 4. SET UP & INSTALLATION ..................9 5.HOW TO PLAY ....................... 17 6.

  • Page 4: Important Safety Instructions

    Jetball Alley Single GMP Manual Thank you for purchasing Jetball Alley. We hope you enjoy the product. This manual contains valuable information about how to operate and maintain your game machine properly and safely. It is intended for the owner and/or personnel in charge of product operation.
  • Page 5 Jetball Alley Single GMP Manual Use the following safety guidelines to help ensure your own personal safety and to help protect your equipment and surrounding environment from potential damage. This product is an indoor game machine. Do not install outdoors.

  • Page 6: Specifications

    Jetball Alley Single GMP Manual 1. SPECIFICATIONS Rated power supply: AC110V~ 50/60Hz; AC220V-240V~ 50/60Hz Min. Power consumption: 300W Max. Power consumption: 350W Dimension: W28.44×D122.11×H87.92in W722.4×D3101.5×H2233 (mm) Weight：Approximately 601.8 lb/273kg Model No: C-578 Part No: J127 NOTICE: After turning off the game, please wait at least 1 minute before restarting again.
  • Page 7 Jetball Alley Single GMP Manual This machine will be divided into two parts during transportation. Back Cabinet: W28.44×D45.79×H70.04 in W722.4 ×D1163 ×H1779 mm Ally part: W28.15×D85.63×H26.62 in W715 ×D2175 ×H676 mm Note: Game specifications are subject to change without notice.

  • Page 8: Contents Of The Accessory Kit

    Jetball Alley Single GMP Manual 2. CONTENTS OF THE ACCESSORY KIT Open the package and make sure all the items are included: Following accessories Part No. Code Name SPEC Picture Φ5×20mm T10A 1 J127-426-000 21901000013 Fuse 250VAC 2 J127-803-000 23301000001 Power cord 3×16AWG 1.8M...

  • Page 9: Part Name

    Jetball Alley Single GMP Manual 3. PART NAME Key Components Marquee Assembly Monitor Lane Ball Exit Ready for Card Reader Coin Mechanism Ticket Dispenser Ready for DBV 10/12/2019...

  • Page 10: Set Up & Installation

    Jetball Alley Single GMP Manual 4. SET UP & INSTALLATION NOTICE We do not recommend using power tools as they may cause damage. This product is an indoor game machine. Do not install outdoors.  Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid.
  • Page 11 Jetball Alley Single GMP Manual 4.3 Play Zone This machine requires space for playing and for maintenance as shown below. Leave space around the game upon installation: Service area: 20 in Service area Play area NOTICE Your unit must be leveled to operate properly.
  • Page 12 This machine is divided into 6 parts: Main cabinet(1 pcs); Lane assembly(1 pcs); Baffle plate(2 pcs); Net A(4 pcs); Net B(1 pcs); Marquee short brackets(2 pcs). Please contact UNIS Service in case of any abnormality. Main cabinet Baffle plate...
  • Page 13 Jetball Alley Single GMP Manual Step 1 Turn the Monitor assembly horizontal as shown below. Turn the Glass frame to the position shown below. Note: Staffs need to hold the Monitor assembly and the Glass frame during the installation. Monitor assembly...
  • Page 14 Jetball Alley Single GMP Manual Step 4 Locate Lane assembly. Unlock and remove 2 Lane side plates. Locate Monitor assembly. Place the other side of the Baffle frame downward as shown below and stick 2 erection columns in 2 mounting metal plates on the Lane assembly. Install two lane side plates back.
  • Page 15 Jetball Alley Single GMP Manual Rectangle: 3 black cross recessed pan head screws Irregular circle: 7 black cross recessed pan head screws (M4×20) Circle: 3 black cross recessed pan head screws (M4×35) Step 7 Place Net B on the Baffle plate. 4 ends of the Net B are with blocks. Baffle plate screws are attached.
  • Page 16 Jetball Alley Single GMP Manual 4.5 Voltage Conversion (110V convert to 220V) Step 1 Power off the machine. Step 2 Locate the Front door and open the Front door. Step 3 Pull the Electrical component base plate out. Locate the PC. Toggle the switch from 115V to 230V on the PC.
  • Page 17 Jetball Alley Single GMP Manual Step 5 Locate the power supply. Toggle the switch from 115V to 230V on the Power supply. 4.6 Card Reader Installation Safety Notice Take precaution to assure that all wiring voltages are confirmed prior to installation of card reader.

  • Page 18: How To Play

    Jetball Alley Single GMP Manual 5.HOW TO PLAY 5.2 Roll the ball to hit the hole. The ball 5.1 Insert coins to play/Swipe card/ hits the hole and the player gets score. Insert cash to play. 5.3 Hit different holes and achieve different combinations(Combo;High Score Combo;Highest Score Combo).

  • Page 19: Game Option

    Jetball Alley Single GMP Manual 6. GAME OPTION 6.1 Adjustment button instruction Open the coin door and there is a meter panel. Press Settings button to - Volume+ ON-OFF enter the setting menu. Settings Test Reset 6.2 Setting menu 6.2.1 Main menu 6.2.2 Basic Setting...
  • Page 20 Jetball Alley Single GMP Manual 6.2.3 Customized Setting Options Adjustment Value Instruction Photo Restore ON/OFF Save photo or not Photo Time 1_3_5_10 Game Time 30_45_60_75_90 Basic Score 10_20_30_40_50 Game start hole score Bottom Hole Score Base bottom hole score Combo Multiple...
  • Page 21 Jetball Alley Single GMP Manual 6.2.4 Ticket Setting Options Adjustment Value Instruction Ticket Out OFF_ON Divided by 2 OFF_ON 2 tickets equals 1 ticket Out Of Ticket Store in memory_Call Attendant Base On Point_Fixed Ticket_Base On Ticket Mode Stage Mercy Ticket...
  • Page 22 Jetball Alley Single GMP Manual 6.2.5 Calibration Options Adjustment Value Flip Horizontally Screen Flip Horizontally Flip Vertically Screen Flip Vertically Web Cam Calibration Back&Save Back 6.2.6 Input Test Options Adjustment Value Instruction Hole Sensor 1 OFF_ON Hole Sensor 2 OFF_ON...
  • Page 23 Jetball Alley Single GMP Manual 6.2.8 Game Reset 6.2.9 Date/Time Setting Options Options Year Factory Restore Month Reset Basic Setting Reset Customized Setting Hour(24) Clear All Records Minute Second Clear Owed Ticket Back&Save Clear Unused Coin Back Back 6.2.11 Daily Record 6.2.10 Bookkeeping...

  • Page 24: Troubleshooting

    Jetball Alley Single GMP Manual 7. TROUBLESHOOTING 7.1 Common Problem Please confirm that all connectors fit tightly. Symptom Possible Cause Recommended action Frame assembly connector is Game will not Check connector. loose. start Frame assembly fault Contact with UNIS Service.
  • Page 25 Jetball Alley Single GMP Manual If you see following error signs showing on the display, please try the recommended action. Display Possible Cause Recommended action Check and reconnect the The connection part of the loose ports of the PC or IO IO board and PC are loose.
  • Page 26 Jetball Alley Single GMP Manual 7.2 System Recovery Operation (NOTE: Do not disconnect power during this process.) 1. Turn off the game. Remove the recovery stick from the machine. (Note: This process may take up to 60 minutes) Insert the recovery stick into the port at the back of the computer.

  • Page 27: Maintenance & Inspection

    Jetball Alley Single GMP Manual 8.MAINTENANCE & INSPECTION 8.1 Safety Check Check the points listed before operating the machine. These checks are necessary for safe machine operation: 1. Test game before operation each day. 2. Conduct monthly routine checks of game components to ensure good working condition.
  • Page 28 Jetball Alley Single GMP Manual 2.Locate Sensor light board. Utilize Phillips screwdriver to loosen 2 screws on the Sensor metal plate. Take Sensor metal plate off. Note: It is the same installation method on the other three Sensor metal plates.
  • Page 29 Jetball Alley Single GMP Manual 8.5 Motor Replacement Instruction 1. Power off the machine. Utilize Keys to open the Ball track cover. 2. Locate the Motor assembly. Unplug the motor connector. Utilize Phillips screwdriver to loosen the screws to remove Motor assembly.
  • Page 30 Jetball Alley Single GMP Manual 4. Loosen the screw to remove Motor mounting plate. Motor mounting plate Screw 5.Loosen 4 screws to remove Motor fixing plate. Motor fixing Screw plate Motor 6.Replace with a new Motor and install it in reversed order.
  • Page 31 Jetball Alley Single GMP Manual 2. Locate the Sensor. Unplug Sensor connector. Twist the sensor to remove sensor as arrow direction. Connector Sensor 3. Replace with the new Sensor and install it in reversed order. 10/12/2019...

  • Page 32: Overall Construction

    Jetball Alley Single GMP Manual 9.OVERALL CONSTRUCTION 9.1 General Assembly Part No. Code No. Name 1 J127-106-000 20211904005 L up net J127-104-000 20211904002 L bottom net J127-406-000 25300171001 171 Lock 3 J127-107-000 20211904007 L triangle plate 4 J127-108-000 20211904008 R triangle plate...
  • Page 33 Jetball Alley Single GMP Manual 9.2 Lane Assembly Part No. Code No. Name 1 J127-126-000 20211904022 Sensor fixing plate 1 2 J127-188-000 20211904059 R supporting plate 1 3 J127-197-000 20211904063 Protective plate G 1 4 J127-220-000 20211904081 Blocking plate 5 J127-191-000 20611904006 L back cover plate 1...
  • Page 34 Jetball Alley Single GMP Manual Part No. Code No. Name 16 J127-704-000 20511904004A Lane plastic 17 J127-195-000 20211904061A Ball plate 18 J127-413-000 25105000014 Sliding rail J127-189-000 20611904004 Ball track cover J127-406-000 25300171001 171 Lock 20 J127-160-000 20611904010 Lane side plastic 1 2...
  • Page 35 Jetball Alley Single GMP Manual Part No. Code No. Name 7 J127-211-000 26000001000C Power supply bracket 8 J127-144-000 20211904031 Protective plate A J127-214-000 26000042001B Wiring box J127-215-000 26000042002B Wiring box cover 10 J127-102-000 20211605043 Power supply fixing plate 1 11 J127-145-000 20211904032...
  • Page 36 Jetball Alley Single GMP Manual 9.5 Ball Hole Assembly Part No. Code No. Name 1 J127-133-000 20211904024 Sensor protect cover 2 J127-125-000 20611904034 Circle rubber 3 J127-128-000 20611904001A Top rod 4 J127-126-000 20211904022 Sensor fixing plate 5 J127-156-000 20211904037 Hole plate fixing plate...
  • Page 37 Jetball Alley Single GMP Manual 9.6 L Baffle Plate Part No. Code No. Name 1 J127-115-000 20611904009 Light strip plastic 2 J127-119-000 20211904016 Light strip pressing plate 2 1 3 J127-113-000 20211904012 Bottom support plate 4 J127-111-000 20211904010 Upper support plate...
  • Page 38 Jetball Alley Single GMP Manual 9.7 R Baffle Plate Part No. Code No. Name 1 J127-115-000 20611904009 Light strip plastic 2 J127-114-000 20211904013 Light strip pressing plate 1 1 3 J127-113-000 20211904012 Bottom support plate 4 J127-111-000 20211904010 Upper support plate...
  • Page 39 Jetball Alley Single GMP Manual 9.8 Back Upper Door Part No. Code No. Name 1 J127-147-000 20611904016 Back upper door foam J127-505-000 20311904024A Back board 1 J127-406-000 25300171001 171 Lock 3 J127-506-000 20311904025A Back board 2 4 J127-123-000 20211904020 Back door side plate 1...
  • Page 40 Jetball Alley Single GMP Manual 9.9 Front Door & Electrical Plate Assembly Part No. Code No. Name 1 J127-547-000 20311904047 Mounting plate 2 J127-212-000 26000007000 Ticket box 3 J127-166-000 20211904044 Base plate 4 J127-218-000 26000064000 Recovery stick plate 1 5 J127-168-000 20211904046 Front door frame...
  • Page 41 Jetball Alley Single GMP Manual 9.10 Motor Assembly Part No. Code No. Name 1 J127-176-000 20211904051 Motor metal plate 1 2 J127-184-000 20211904056 Blocking rod plate 1 3 J127-185-000 20611904027 Rubber 4 J127-183-000 20211904074 Axle 5 J127-181-000 20611904026 Axle sleeve...
  • Page 42 Jetball Alley Single GMP Manual 9.11 Net B Part No. Code No. Name 1 J127-120-000 20211904017 Net B fixing plate 1 1 2 J127-121-000 20211904018 Net B fixing plate 2 1 3 J127-122-000 20211904019 Net B 9.12 Glass Part No.
  • Page 43 Jetball Alley Single GMP Manual 9.13 Display Assembly Part No. Code No. Name 1 J127-703-000 20511904003 Display plastic 2 J127-201-000 20611904013 Display light strip plastic 1 3 J127-203-000 20211904066 Display fixing plate 4 J127-200-000 20211904064 Display frame 5 J127-202-000 20211904065 Display frame fixing plate 2...
  • Page 44 Jetball Alley Single GMP Manual Part No. Code No. Name 1 J127-209-000 20211904070 Marquee fixing plate 2 J127-206-000 20211904069 Marquee base plate 3 J127-210-000 20211904071 Hinge 4 J127-208-000 20611904015 Light strip plastic 2 5 J127-701-000 20511904001 Marquee plastic 6 J127-207-000 20611904014...
  • Page 45 Jetball Alley Single GMP Manual Part No. Code No. Name J127-101-000 20241708002 Caster plate J127-408-000 25501000003 Caster J127-213-000 26000009000 Caster bracket 10 J127-159-000 20211904039 Frame plate Part No. Code No. Name 1 J127-545-000 20311904045A Support board 2 J127-533-000 20311904018 Connective board...
  • Page 46 Jetball Alley Single GMP Manual 9.16 Cabinet Wooden Assembly Part No. Code No. Name 1 J127-518-000 20311904034A Front top board 2 J127-503-000 20311904022A L side board 3 J127-514-000 20311904032A Top cover board 4 J127-515-000 20311904033A Top board 5 J127-513-000 20311904031A...
  • Page 47 Jetball Alley Single GMP Manual Part No. Code No. Name J127-408-000 25501000003 Caster J127-101-000 20241708002 Caster plate J127-213-000 26000009000 Caster bracket 18 J127-502-000 20311904001 Front board 19 J127-219-000 26000067000 Corner bar 20 J127-521-000 20311904035 Blocking board 21 J127-519-000 20311904004 Ball track board...
  • Page 48 Jetball Alley Single GMP Manual 9.17 Decals Part No. Code No. Name 1 J127-701-000 20511904001 Marquee plastic 2 J127-704-000 20511904004 Lane plastic 3 J127-721-000 25600000108 Ticket decal 4 J127-716-000 20511904016 DBV decal 5 J127-709-000 20511904009 Arrow decal 6 J127-703-000 20511904003...
  • Page 49 Jetball Alley Single GMP Manual Part No. Code No. Name 1 J127-715-000 20511904015 Counter decal 2 J127-726-000 25600000042A Service label(green) 3 J127-733-000 25600000095A Service label L(orange) 4 J127-724-000 25600000036 High voltage label(s) 5 J127-714-000 20511904014 Wiring decal 6 J127-727-000 25600000067A...
  • Page 50 Jetball Alley Single GMP Manual Part No. Code No. Name 18 J127-723-000 25600000016 Power supply SW decal 19 J127-728-000 25600000071 110V decal 20 J127-720-000 20511904020 Lock decal 2 21 J127-729-000 25600000072 220V decal 22 J127-730-000 25600000077 Fuse decal 23 J127-719-000 20511904019...
  • Page 51 Jetball Alley Single GMP Manual 9.18 Electrical Component Card reader Part No. Code No. Name 1 J127-418-000 21107040016 Camera 2 J127-419-000 21201049005 49'' monitor 3 J127-430-000 22002015019 BG5050W light strip 175cm(68.89in) 4 J127-431-000 22002015021 BG5050RGB light strip 185cm(72.83in) J127-428-000 22002011003 BG2835G light strip 155cm(61.02in)
  • Page 52 Jetball Alley Single GMP Manual Part No. Code No. Name 1 J127-423-000 21602020006 Power supply 1 2 J127-425-000 21714000148D Fuse board(UL) 1 3 J127-424-000 21603000027 AC adapter 4 J127-420-000 21501000004 Sensor 5 J127-454-000 23309000348 Cable set 10/12/2019...
  • Page 53 Jetball Alley Single GMP Manual Part No. Code No. Name J127-416-000 21102000106 J127-447-000 23301050002 Power cord J127-466-000 21107290001 Mainboard J127-467-000 21107290002 J127-468-000 21107290003 Memory J127-469-000 21107290004 J127-470-000 21107290005 Video card J127-471-000 21107290008 PC power supply J127-472-000 21107290010 PC fan J127-473-000 21107290011...
  • Page 54 Jetball Alley Single GMP Manual Part No. Code No. Name 1 J127-464-000 26601101654 Chassis assembly of 49'' monitor 1 2 J127-463-000 26601090397 Power board 3 J127-465-000 26601090407 7-key board 4 J127-462-000 26601090396 Driver board 5 J127-452-000 23307020001D DVI cable 6 J127-460-000 29791400001...

  • Page 55: Wiring Diagram

    Jetball Alley Single GMP Manual 10.WIRING DIAGRAM AC IN AC IN 10/12/2019...
  • Page 56 Jetball Alley Single GMP Manual 10/12/2019...
