- Page 1 Panama Dresser Assembly and care instructions...
- Page 2 READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Thank you for purchasing an East Coast product. It’s been carefully designed and constructed to offer quality, safety and reliability for you and your baby. If you have a query about this product or require replacement parts, please contact 01692 408802.
- Page 3 Wooden Parts Drawer Back Drawer Side (L+R) x 3 Drawer Front Drawer Base x 3 Drawer Brace x 3 Changer Back Changer Sides Handle x 3 (L+R) Changer Front Changer Base Sides (L+R) Panel Joiner Upper Back Rail Front Rail Lower Back Rail Base Back Panels...
- Page 4 Assembly 1 E x 8 Base Legs Assembly 2 D x 3 Side (L) F x 2 Note: Repeat for other side (R).
- Page 5 Assembly 3 C x 6 Upper Back Rail Lower Back Rail Upper Front Rail F x 6 Note: Ensure cam is Note: Repeat for pointing along the other end length of insert. Assembly 4 Upper Back Rail With cam pin inserted, turn Upper Front Rail cam nut clockwise to tighten.
- Page 6 Assembly 5 Side (R) With cam pin inserted, turn cam nut clockwise to tighten. Assembly 6 Base + Legs A x 6...
- Page 7 Assembly 7 D x 6 Assembly 8 Note: Ensure cam is pointing along the length of insert. C x 6...
- Page 8 Assembly 9 With cam pin inserted, turn cam nut clockwise to tighten. B x 2 Assembly 10 H x 20 Back Panel (R) Panel Joiner Back Panel (L)
- Page 9 Assembly 11 Changer Back D x 4 D x 4 Changer Left Changer Front C x 4 C x 4 Changer Right Assembly 12 Changer Base With cam pin inserted, turn cam nut clockwise to tighten.
- Page 10 Assembly 13 G x 2 Assembly 14 Drawer Front Handle G x 2 I x 2 Repeat for other side Drawer Side (L) Drawer Support Drawer Side (R)
- Page 11 Assembly 15 J x 2 Base J x 2 K x 4 Drawer Back Assembly 16...
- Page 12 Assembly 11 Assembly 17 The dresser is supplied with a fixing kit which will secure it and help to guard against accidental tipping. The dresser is supplied with a fixing kit which will secure it and help to guard against accidental tipping. WARNING : Installation only to be carried out by a competent person.
-
Page 13: Care And Maintenance
Do not use the dresser if any of the parts are broken, torn or missing. Any additional or replacement parts can only be obtained from the manufacturer or the distributor. East Coast Nursery Ltd, Robertson House North Walsham, Norfolk, NR28 0BX, UK...
