Summary of Contents for EAST COAST Montreal
- Page 1 Montreal Dresser Assembly and care instructions...
- Page 2 RETAIN FOR FUTURE REFERENCE: READ CAREFULLY Thank you for purchasing an East Coast product. It’s been carefully designed and constructed to offer quality, safety and reliability for you and your baby. If you have a query about this product or require replacement parts, please contact 01692 408802.
- Page 3 Wooden Parts Changer Back Changer Front Changer Side x 2 Top Panel Lower rear Crossbar Upper Rear Crossbar Upper Front Crossbar Plain Crossbar x 3 Side Panel x 2 Base Back Panel x 2 Drawer Side (L&R) x 3 Drawer Brace x 3 Drawer Back x 3 Drawer Front x 3 Drawer Base x 3...
- Page 4 Assembly 1 NOTE: Take care to insert the dowels into the correct holes as indicated. Repeat All Crossbars for the opposite end of each crossbar. (Total 24 dowels) A x 24 Assembly 2 Side Panel A x 2 Repeat for the opposite panel. (Total 4 dowels)
- Page 5 Assembly 3 Plain Crossbar x 3 Upper Front Crossbar Upper Rear Crossbar H x 15 (45mm) Lower Rear Crossbar Assembly 4 Base I x 3 H x 2...
- Page 6 Assembly 5 I x 3 F x 6 H x 6 Assembly 6 Top Panel G x 5...
- Page 7 Assembly 7 Back Panel NOTE: Slot to top K x 28 Back Panel Assembly 8 Drawer Brace Drawer Front Drawer Side (R) Drawer Side (L) Drawer Back Drawer Base D x 9 Repeat for other 2 drawers...
- Page 8 Assembly 9 E x 2 Handle Assembly 10 Changer Front B (each end) A x 2 (each end) Changer Back A x 2 Changer Side (x 2)
- Page 9 Assembly 11 Changer Side G x 2 Changer Back C x 2 NOTE: Insert Cam Nut (Part C) with Changer Side arrowed slot facing the Changer Front. To lock Changer Front in place, Changer Front turn Cam nuts (part C) 1/2 turn clockwise with a large flat-bladed screwdriver after assembly.
- Page 10 Assembly 13 The dresser is supplied with a fixing kit which will secure it and help to guard against accidental tipping. WARNING : Installation only to be carried out by a competent person. Check the suitability of the wall before fitting. Screw (15mm) Screw (25mm) Washer x 2...
-
Page 11: Care And Maintenance
Do not use the dresser if any of the parts are broken, torn or missing. Any additional or replacement parts can only be obtained from the manufacturer or the distributor. For customer care or enquiries: Call: 01692 408802 Email: nursery@east-coast.co.uk East Coast Nursery Ltd. Robertson House, North Walsham, Norfolk, NR28 0BX eastcoastnursery.co.uk 6898_V3...
