Xplained Pro

Xplained Pro is an evaluation platform that provides the full Atmel microcontroller experience. The platform
consists of a series of Microcontroller (MCU) boards and extension boards that are integrated with Atmel
Studio, have Atmel Software Framework (ASF) drivers and demo code, support data streaming and more.
Xplained Pro MCU boards support a wide range of Xplained Pro extension boards that are connected through
a set of standardized headers and connectors. Each extension board has an identification (ID) chip to uniquely
identify which boards are mounted on a Xplained Pro MCU board. This information is used to present relevant
user guides, application notes, datasheets and example code through Atmel Studio. Available Xplained Pro
MCU and extension boards can be purchased in the
3.1

Hardware Identification System

All Xplained Pro compatible extension boards have an Atmel ATSHA204 CryptoAuthentication™ chip mounted.
This chip contains information that identifies the extension with its name and some extra data. When an
Xplained Pro extension board is connected to an Xplained Pro MCU board the information is read and sent
to Atmel Studio. The Atmel Kits extension, installed with Atmel Studio, will give relevant information, code
examples and links to relevant documents.
data fields stored in the ID chip with example content.
Table 3-1. Xplained Pro ID Chip Content
Data Field
Manufacturer
Product Name
Product Revision
Product Serial Number
Minimum Voltage [mV]
Maximum Voltage [mV]
Maximum Current [mA]
3.2

Standard Headers and Connectors

3.2.1

Xplained Pro Standard Extension Header

All Xplained Pro kits have one or more dual row, 20-pin, 100mil extension headers. Xplained Pro MCU boards
have male headers while Xplained Pro extensions have their female counterparts. Note that all pins are not
always connected. However, all the connected pins follow the defined pin-out described in
Pro Extension Header" on page
Xplained Pro extensions to Xplained Pro MCU boards and to access the pins of the target MCU on Xplained
Pro MCU board directly.
Table 3-2. Xplained Pro Extension Header
Pin number
1
2
3
4
5
6
7
8
1
http://store.atmel.com/
Table 3-1, "Xplained Pro ID Chip Content" on page 6
Data Type
ASCII string
ASCII string
ASCII string
ASCII string
uint16_t
uint16_t
uint16_t
6. The extension headers can be used to connect a wide variety of
Name
ID
GND
ADC(+)
ADC(-)
GPIO1
GPIO2
PWM(+)
PWM(-)
1
Atmel Web Store .
Example Content
Atmel'\0'
Segment LCD1 Xplained Pro'\0'
02'\0'
1774020200000010'\0'
3000
3600
30
Description
Communication line to the ID chip on extension board.
Ground.
Analog to digital converter , alternatively positive part of
differential ADC.
Analog to digital converter , alternatively negative part of
differential ADC.
General purpose I/O.
General purpose I/O.
Pulse width modulation , alternatively positive part of
differential PWM.
Pulse width modulation , alternatively positive part of
differential PWM.
