- Page 1 INSTALLATION GUIDE Solitaire 710-II and SMART (740) Series AMM and AADB Models PK2710-T...
- Page 2 © 2002 Kaba Ilco, Inc. All trademarks and registered trademarks are the property of their respective owners. 7 1 0 - I I / 7 4 0 S E R I E S I N S TA L L AT I O N G U I D E • P K 2 7 1 0 / 0 8 / 0 2...
- Page 3 7 1 0 - I I / 7 4 0 S E R I E S I N S TA L L AT I O N G U I D E • P K 2 7 1 0 / 0 8 / 0 2 P a g e 3...
-
Page 4: Introduction And Disclaimers
Please read and follow all directions carefully. These instructions are designed for use by maintenance professionals or lock installers who are familiar with common safety practices and competent to perform the steps described. Kaba Ilco is not responsible for damage or malfunction due to incorrect installation, however arising. - Page 5 I I I INSTALL THE STRIKE Mark the Location of the Strike Align the paper template at the desired handle height ( ), and along the vertical center line of the mortise ( ), which is also the center line of the door, allowing for any bumpers on the door frame.
-
Page 6: Prepare The Door
I V INSTALL THE MORTISE If using the installation jig to prepare the door, refer to the instructions provided with the jig. After preparing the holes in the door, proceed with step 2 below. Prepare the Door Door With the door almost closed, mark the center of the Strike edge of the door at the handle height as deter-... - Page 7 V PREPARE THE MECHANICAL OVERRIDE If you have an electrical override lock, continue on page 8. Key-in-Knob Mechanical Override ” to ” (6.3 to 16mm) Assemble the key cylinder (D) in the rear of the Hold the outside housing against the door. The Break off the tailpiece at the mark using two outside housing, and secure it using the bridge tailpiece should extend between...
-
Page 8: Door Handing
V I INSTALL THE LOCK Set Override Hand Set Thumbturn Hand For mortise models with a thumbturn on the inside housing, the groove on the thumbturn spindle (W) must be positioned according to the following table prior to installation. (The thumbturn must be in the vertical position as shown.) Door Handing align groove with... -
Page 9: Exploded View
V I INSTALL THE LOCK Exploded View Electrical Override Models Detail: Mechanical Override Models 17. Snap the battery connector (L) onto the sealed battery pack (M) and place the battery pack in the top of the inside housing. Secure the battery cover (O) using the 6-32 x 3/8" (10mm), 5/64" hex head screw (N). NOTE: If the lock makes a continuous buzzing noise, the mortise motor is running continuously. - Page 10 V I I TEST THE OPERATION OF THE LOCK Caution! Perform the following procedures in order, Outside Lever with the door OPEN unless otherwise indicated. Turn the outside lever downward. The latch bolt does not retract. If the latch bolt retracts, verify that the batteries are properly Inside Lever installed and that the mortise handing corresponds to the lock handing.
- Page 11 4. Any damaged parts must be replaced, including the drill plate. A new drill plate can be purchased from Kaba (see catalog). To install the drill plate, the lock must be removed from the door.
- Page 12 Kaba Lodging Systems 7301 Boul. Décarie Montréal (QC) H4P 2G7 Technical Support: 1.800.906.4526 Customer Service: T: 1.877.468.3555 F: 514.735.6589 General Information: www.kabalodging.com Online Consumable Orders: www.keycard.com To access all of our easy steps,please visit our Support Website: http://connect.kabalodging.com...
