- Page 1 Service Installation instructions Audi A4 Avant 2016▶ Load guard for scope of delivery 8W9.017.221 Audi Genuine Accessories Edition 01 Service Department. Technical Information...
- Page 2 ..................All rights reserved. No reproduction without prior agreement from publisher. Copyright © 2015 Audi AG, Ingolstadt Printed in Germany...
- Page 3 Text with this symbol indicates the risk of damage to your vehicle. Note Text with this symbol contains additional information. AUDI AG will not accept responsibility in the event of fail- ure to comply with these assembly instructions. Special notes on using the load guard. WARNING It is forbidden to transport people behind the load guard.
- Page 4 Installation instructions - Audi A4 Avant 2016 ▶ Edition 01 Parts overview Parts overview for load guard The set 8W9.017.221 comprises the following components: 1 - Load guard 2 - Retaining bracket (2x) 3 - M8 star grip nut (2x) 4 - Star grip screw M8 (1x) ◆ For retaining plate...
- Page 5 Installation instructions - Audi A4 Avant 2016 ▶ Edition 01 Fitting the load guard Sequence of operations Note When the load guard is installed, the net partition in the rear of the vehicle (luggage compartment) cannot be used. – Check that the assembly set is complete.
- Page 6 Installation instructions - Audi A4 Avant 2016 ▶ Edition 01 – Move the retaining bracket -2- for the load guard -1- into the installation position on the correct side by moving it in the -direction of arrow a- and align.
- Page 7 Installation instructions - Audi A4 Avant 2016 ▶ Edition 01 Concluding operations Caution Once again check that all star grip screws and star grip nuts are securely fitted. – Fold the rear seat backrest back, making sure that the load guard does not rub against it.
- Page 8 Installation instructions - Audi A4 Avant 2016 ▶ Edition 01 Change history Version Date Reason for change 4 Change history...
