- Page 1 Service Installation instructions Ski and luggage box For scope of delivery 8X0.071.200, 8V0.071.200, 8K0.071.200 Audi Genuine Accessories Edition 12/2014 Service Department. Technical Information...
-
Page 2: Table Of Contents
................... All rights reserved. No reproduction without prior agreement from publisher. Copyright © 2016 Audi AG, Ingolstadt Printed in Germany... -
Page 3: General Notes
Text with this symbol indicates the risk of damage to your vehicle. Note Text with this symbol contains additional information. Audi AG shall not accept responsibility in the event of fail- ure to comply with these installation instructions 1 General notes... -
Page 4: Safety Notes
WARNING Repairs or the replacement of parts must only be per- formed by a qualified workshop. It is recommended that genuine spare parts available from your Audi partner are used. Caution Do not enter a car wash with the ski and luggage box and roof bars mounted. -
Page 5: Safety Notes To Be Checked Before And After Each Journey And When In Use
Installation instructions - Ski and luggage box Edition 12/2014 Note ◆ Observe the relevant statutory regulations for using ski and luggage boxes in other countries. ◆ Remove the ski and luggage box when not in use. ◆ We reserve the right to make technical changes. Safety notes to be checked before and after each journey and when in use WARNING... -
Page 6: Sensitivity To Side Winds
Installation instructions - Ski and luggage box Edition 12/2014 – Calculate the height of the vehicle -a- with ski and luggage box fitted and write it down on the safety sticker supplied. – Place the safety sticker clearly in the driver's field of vision. 2.3.2 Sensitivity to side winds WARNING The load affects driving and braking behaviour and the... -
Page 7: Safety Notes For Loading
2.4.1 Permissible roof load and loading Caution The maximum load of the ski and luggage boxes 8X0.071.200 and 8K0.071.200 is 75 kg (165 lbs) and must not be exceeded. The maximum load of the ski and luggage box 8V0.071.200 is 60 kg (132 lbs) and must not be exceeded. -
Page 8: Panorama Glass Roof Opening Area
Installation instructions - Ski and luggage box Edition 12/2014 2.4.3 Panorama glass roof opening area WARNING If you install the ski and luggage box on a vehicle with a Panorama glass roof, do not open the Panorama glass roof — risk of damage! 2.4.4 Effect of heat –... -
Page 9: Scope Of Delivery And Overview Of Components
Installation instructions - Ski and luggage box Edition 12/2014 Scope of delivery and overview of components Scope of delivery Quantity Component Ski and luggage box (including 4 fasteners) Tensioning straps Keys Safety sticker Installation instructions Overview of components 1 - Ski and luggage box 2 - Tensioning straps 3 - Keys 4 - Safety sticker... -
Page 10: Key Number
– Make a note of the key number in the space provided beside the illustration of the key. Note ◆ The key number is needed to order a suitable replacement key, ◆ which you can obtain from your Audi partner or a qualified workshop. 3 Scope of delivery and overview of components... -
Page 11: Ski And Luggage Box
The largest distance -a- possible should always be selected. To make sure the ski and luggage box is fitted securely using the fasteners provided, a freely accessible carrier bar area of min. -b- must be available; see table Ski and lug- 8X0.071.200 8V0.071.200 8K0.071.200 gage box Distance -b-... - Page 12 Installation instructions - Ski and luggage box Edition 12/2014 The ski and luggage box is equipped with sliding fasteners -1-, which allow the box to be fitted without the need for any tools. ⇒ “ Opening and closing the – Open the ski and luggage box ski and luggage box”...
- Page 13 Installation instructions - Ski and luggage box Edition 12/2014 – Take care there are identical overhangs to the front -a- and rear -b- of the roof bars. Caution Take care not to damage the roof with the fasteners when fixing the ski and luggage box in position. On vehicles with a tailgate, there may be circumstances in which the tailgate makes contact with the ski and luggage box when it is opened.
-
Page 14: Removing The Ski And Luggage Box
Installation instructions - Ski and luggage box Edition 12/2014 – Check that the ski and luggage box is fixed and securely at- tached. WARNING If the ski and luggage box is only partly or insufficiently attached, there is the risk that it will become loose during travel and fall from the roof —... -
Page 15: Loading The Ski And Luggage Box
– Distribute load as shown in the diagram. Note ◆ Heavy loads should be positioned in the centre. ◆ The maximum load for roof boxes 8X0.071.200 and 8K0.071.200 of 75 kg/165 lbs must not be exceeded. ◆ The maximum load for roof box 8V0.071.200 of 60 kg/132 lbs must not be exceeded. -
Page 16: Cleaning Instructions
Locks must be lubricated with a spray lubricant (lubricant must be kept away from the plastic surface). Technical data Ski and luggage box 8X0.071.200 8V0.071.200 8K0.071.200 Intrinsic weight 16 kg/35 lbs 14 kg/31 lbs 19 kg/42 lbs Max.
