ACUSON S2000
Installation Instructions
System
System Delivery Procedure
This document is valid for:
ACUSON S2000
BJ
n.a.
Siemens
Print No.:
US15-101.812.01.02.02
Replaces:
US15-101.812.01.01.02
Part No.:
Ultrasound
US
2010
© Siemens
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
written
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 05.10
n.a.

Advertisement

Table of Contents
loading

Related Manuals for Siemens ACUSON S2000

Summary of Contents for Siemens ACUSON S2000

  • Page 1 ACUSON S2000 Installation Instructions System System Delivery Procedure This document is valid for: ACUSON S2000 2010 © Siemens The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for Siemens n.a.
  • Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or authorized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service proce- dures.
  • Page 3 Further, because unauthorized use of such computer programs will leave Siemens without an adequate remedy at law, Buyer agrees that injunctive or other equitable relief will be appropriate to restrain such use, threatened or actual.

  • Page 4: Table Of Contents

    Packaging the system ..........39 Page 4 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10...

  • Page 5: Overview

    1System Delivery Procedure The System Delivery procedure provides instructions to power on and perform a courtesy check of an ACUSON S2000 ultrasound imaging system at a customer site. This document is confidential and to be used by authorized personnel only.

  • Page 6: Before You Start

    Remember; DO NOT unpack the system inside the truck or on the lift gate. Once you are in the delivery location, check to be sure that there is enough space to remove the system from the shipping container. Page 6 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10...

  • Page 7: Check For Shipping Damage

    Check the tip and tell on the crate and be sure that it has not been activated. Also check to be sure that the shock indicator is not tripped. Contact Agent or Siemens immediately if shipping damage indicators are activated, or if there appears to be any shipping damage.

  • Page 8: Set Up The System

    1. Remove the shipping label and the packing / unpacking instructions from the outside of the shipping container. Set them aside for the customer. 2. Remove the outer packaging. a) Cut the two straps (1/Fig. 1 / p. 9) that secure the outer packaging. Page 8 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
  • Page 9 Remove the rear spacer and top accessory box (1,5/Fig. 2 / p. 10), if necessary. b) Remove the foam supports from the front and back of the monitor (2,4/Fig. 2 / p. 10). Page 9 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 10 Coro clips (8 places) Pos. 7 Inner sleeve 6. Carefully remove the plastic wrapping that secures the keyboard, peripherals, and fil- ters to the system's frame. 7. Install the roll-out ramps. Page 10 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
  • Page 11 S2000 -- Uncrating Positions Pos. 1 Bolt (8 places) Pos. 2 Rear Bracket Pos. 3 Accessory Box “B” Pos. 4 Ramp 2 Pos. 5 Ramp 1 Pos. 6 Front Bracket Page 11 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 12 System Delivery Procedure Fig. 4: S2000 -- Crating/Uncrating Positions Pos. 1 Rear Bracket Pos. 2 Ramp 1 Pos. 3 Ramp 2 Pos. 4 Bolts (4 places) Pos. 5 Front Bracket Page 12 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...

  • Page 13: Inspect And Set Up The System

    Pull out the filter located at the rear of the system and check that the filter screen is in place. 4. Position the ultrasound system in the office or exam room and set the brakes. Page 13 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...

  • Page 14: Inventory The System

    1. Unpack the accessories. 2. Inventory all items to ensure serial numbers match the packing list, and are present. 3. Contact Siemens immediately if the packing list and peripherals delivered do not match or are missing. Power Up the System 1.
  • Page 15 5. Verify that the following occurs within the first four seconds of the boot sequence: a) The lower-rear panel LEDs 1,2,3,4,5, and 6 illuminate green. Reference (4/Fig. 7 / p. 14) Page 15 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 16 IO Panel -- LED Lights 6. Verify system completes the boot sequence to imaging without displaying any error messages. NOTE The boot sequence completes in approximately three to five minutes. Page 16 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
  • Page 17 In the event that the system does not power up, the system is in need of servicing to resolve the problem. Contact the Siemens Factory Representative For CSEs only, contact Siemens Uptime Service Cen- ter,. Page 17 of 40 Siemens US15-101.812.01.02.02...

  • Page 18: Verifications

    System Delivery Procedure Verifications Control Panel Overview Refer to the following figures to locate the controls used throughout the verifications steps. Fig. 10: Control Panel -- Lower UI Page 18 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...

  • Page 19: Verify Control Panel Raises And Lowers

    If the S2000 system is configured for both a color printer and a black and white printer, or a DVD Recorder, the control panel will not raise or lower. Proceed to (Verify Transducer Initialization / p. 20). Page 19 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...

  • Page 20: Verify Transducer Initialization

    4. Verify one at a time, each transducer shipped with the system in any of the verified transducer ports. 5. Leave the last transducer being verified connected to the transducer port. Page 20 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10...
  • Page 21 Fig. 14: Transducer - Locked NOTE When plugging in or removing transducers, be sure to move them straight in, and straight out, to avoid bending pins or connector ports. Page 21 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 22 2. Press the 2D knob. (3/Fig. 11 / p. 19) 3. Select the name of the connected transducer from the transducer list located in the upper-left corner of the monitor. Page 22 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
  • Page 23 Connecting or disconnecting the transducers while in imag- CAUTION ing mode may affect the image. Put the system in Freeze mode prior to connecting or disconnecting transducers. Page 23 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 24 2. Connect the transducer shipped with the system to the center transducer port. a) Roll the trackball to position the pointer over the Image on-screen button in the lower-left corner. b) Press the Select key. Fig. 20: Page 24 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
  • Page 25 Roll the trackball to position the pointer over the name of the connected transducer. NOTE When the system displays the transducer name, the system has recognized the connected transducer. Page 25 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 26 Connecting or disconnecting the transducers while in imag- CAUTION ing mode may affect the image. Put the system in Freeze mode prior to connecting or disconnecting transducers. 1. Press the Freeze button. Fig. 25: Page 26 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
  • Page 27 This activates the port the transducer is connected to and unfreezes the image, returning to imaging mode. f) Press the Select key. Fig. 28: 3. Press the 2D knob (3/Fig. 11 / p. 19). Page 27 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...

  • Page 28: Verify Color Mode

    2. Rotate the C knob (7/Fig. 11 / p. 19) to enable color imaging. The region of interest (ROI) (green) and the color tools are active. 3. Adjust the ROI position. Page 28 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...

  • Page 29: Verify Doppler Mode

    It may be necessary to rotate the PW knob (9/Fig. 11 / p. 19) clockwise to see the strip. 4. Press the M knob (1/Fig. 11 / p. 19) again to exit Doppler Mode. Page 29 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...

  • Page 30: Verify Printer Operation

    1. Verify each peripheral is powered on. NOTE The peripheral LEDs illuminate green when the peripherals are powered on. If a peripheral is not powered on, press the POWER button of that peripheral. Page 30 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
  • Page 31 3. For additional (black and white or color) printers that do not print in the above steps: a) Press the 2D knob (3/Fig. 11 / p. 19) to return to the 2D mode. Page 31 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 32 Press the Store key (Fig. 33 / p. 30). d) Verify an image printed on the B&W printer. NOTE Contact the Siemens Factory Representative to resolve any printer problems. For CSEs only: Contact Siemens Uptime Service Center. Page 32 of 40 ACUSON S2000 US15-101.812.01.02.02...

  • Page 33: Verify Dvd Recorder (Dvr) Operation (If Installed)

    Fig. 35: DVR connected to S2000 I/O ports 2. Power on the front of the DVR, by pressing the Operate button. 3. Insert a blank DVD Disk in the DVR. Page 33 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 34 The menu will change from “Ready” to “Recording”. c) Press the DVR button (4/Fig. 11 / p. 19) to stop the image recording 7. View the images. Page 34 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
  • Page 35 Fig. 38: DVR View Screen Controls (lower right corner of View Screen) 8. Exit the DVR View screen by clicking the red “X” on the screen, or clicking the “Escape” key on the Control Panel keyboard. 9. Eject the DVD. Page 35 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 36 System Delivery Procedure NOTE Contact the Siemens Factory Representative or Siemens Uptime Service Center to resolve any DVR problems. Page 36 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...

  • Page 37: Power Down System

    Contract that the system has powered up correctly. Now the system may be powered down as described below. 1. Press the Power button on the Control Panel. The system displays a shut down dialog box. 2. Select the Shutdown on-screen button. Page 37 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...

  • Page 38: Administration

    Customer Site • Remove all packing material, trash, and the shipping crate from the customer site. • This is a Controlled, Confidential document. Remove from customer site and destroy the document. Page 38 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...

  • Page 39: Crating The System

    9. Place accessory box in front of monitor, and spacer box at back of system. 10. Install outer sleeve (3 Corro clips). 11. Install lid. Secure with two straps around girth (Fig. 1 / p. Page 39 of 40 Siemens US15-101.812.01.02.02 ACUSON S2000 05.10 Ultrasound...
  • Page 40 System Delivery Procedure Fig. 39: S2000 -- Crating/Uncrating Positions Pos. 1 Rear Bracket Pos. 2 Ramp 1 Pos. 3 Ramp 2 Pos. 4 Bolts (4 places) Pos. 5 Front Bracket Page 40 of 40 ACUSON S2000 US15-101.812.01.02.02 Siemens 05.10 Ultrasound...
