Teknik Barrister Home Lift Up 5420329 Instruction Booklet

Coffee table
Hide thumbs

Advertisement

Quick Links

Download this manual
www.teknikoffice.co.uk
Barrister Home Lift Up Coffee Table
Model 5420329
Teknik
It's addicting.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Barrister Home Lift Up 5420329 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teknik Barrister Home Lift Up 5420329

Summary of Contents for Teknik Barrister Home Lift Up 5420329

  • Page 1 Teknik www.teknikoffice.co.uk It's addicting. Barrister Home Lift Up Coffee Table Model 5420329 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
  • Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 6-23 Hammer Not actual size Skip the power trip. This time. Page 2...

  • Page 3: Part Identification

    Now you know Part Identifi cation our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. UPPER RIGHT END (1) UPPER LEFT END (1) LOWER END (2)

  • Page 4: Hardware Identification

    Hardware Identifi cation å You may receive extra hardware with your unit. TWIST-LOCK ® HIDDEN CAM - 12 CAM DOWEL - 12 FASTENER - 10 MOLDING WOOD DOWEL - 2 METAL BRACKET - 4 CONNECTOR - 4 31G CORNER BRACKET - 4 SUPPORT BRACKET - 2 BUMPER - 6 23M LIFT TABLE...
  • Page 5 Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. BLACK 9/16" LARGE HEAD SCREW - 48 SILVER 1-1/8" FLAT HEAD SCREW - 8 BLACK 3/4" MACHINE SCREW - 4 BLACK 3/4" PAN HEAD SCREW - 2 113S BLACK 1-15/16"...
  • Page 6 Step 1 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push a SAUDER TWIST-LOCK® å FASTENER (10F) into the large holes in the UPPER ENDS (A and B) and PANELS (O).
  • Page 7 Step Step 2 Push twelve HIDDEN CAMS (1F) into the UPPER ENDS (A and B), å LOWER ENDS (C), and UPRIGHT (D). Then, insert the metal end Some assembly of a CAM DOWEL (2F) into each HIDDEN CAM. (and snacks) required. Do not tighten the HIDDEN CAMS in this step.
  • Page 8 Step Step 3 Tap four MOLDING CONNECTORS (17F) into the notches å in the MOLDINGS (K and L). Use your hammer to tap the MOLDING CONNECTORS (17F) into the notches in the MOLDINGS. Flat end Flat end Curved edge Page 8...
  • Page 9 Step Step 4 Fasten the UPPER ENDS (A and B) to the PANELS (O). å Tighten four HIDDEN CAMS. Edge with TWIST-LOCK® FASTENERS Edge with TWIST-LOCK® N E R S T E FASTENERS ® F A - L O I S T i t h f a c S u r...
  • Page 10 Step Step 5 With someone's help, fl ip the UPPER ENDS (A and B) and PANELS (O) over. å Fasten the UPPER ENDS (A and B) and PANELS (O) to the MOLDINGS (K å and L). Tighten ten TWIST-LOCK® FASTENERS. How to use the SAUDER TWIST-LOCK ®...
  • Page 11 Step Step 6 Fasten the SHELF (G) to the UPPER ENDS (A and B) å and PANELS (O). Use eight BLACK 1-15/16" FLAT HEAD SCREWS (113S). 113S BLACK 1-15/16" FLAT HEAD SCREW (8 used in this step) Page 11...
  • Page 12 Step Step 7 Fasten LOWER ENDS (C) to the SHELF (G). Tighten four å HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees S u r f a c i t h H I D D E N S u r f a c i t h o u t H...
  • Page 13 Step Step 8 Insert two WOOD DOWELS (15F) into the holes in å the SHELF (G). Place the UPRIGHT (D) over the WOOD DOWELS å in the SHELF (G). Edge with smaller holes S u r f a c i t h H I D D E N Page 13...
  • Page 14 Step Step 9 Fasten the UPRIGHT MOLDINGS (N) to the UPRIGHT (D). å Tighten four HIDDEN CAMS. Maximum Arrow 210 degrees Slide the END MOLDINGS* (M) onto the notched edges å of the LOWER ENDS (C). Minimum *U.S. Patent No. 5,499,886 190 degrees å...
  • Page 15 Step Step 10 Fasten the BOTTOM (F) to the LOWER ENDS (C) å and UPRIGHT (D). Use six BLACK 1-15/16" FLAT Don't worry. It isn't HEAD SCREWS (113S). Rome. This can be built in a day. 113S BLACK 1-15/16" FLAT HEAD SCREW (6 used in this step) Page 15...
  • Page 16 Step Step 11 Fasten the CORNER BRACKETS (31G) to the BOTTOM (F). Use å eight BLACK 9/16" LARGE HEAD SCREWS (1S). Fasten the SIDE SKIRTS (I) to the CORNER BRACKETS (31G). å Use eight BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16"...
  • Page 17 Step Step 12 Fasten the LONG SKIRTS (H) to the PLINTHS (P). Use å eight SILVER 1-1/8" FLAT HEAD SCREWS (10S). SILVER 1-1/8" FLAT HEAD SCREW (8 used in this step) Surface with more holes Curved edge Curved edge Page 17...
  • Page 18 Step Step 13 Fasten four METAL BRACKETS (4G) to the BOTTOM (F). Use å four BLACK 9/16" LARGE HEAD SCREWS (1S). Fasten the LONG SKIRTS (H) to the BRACKETS (4G and 31G). å Use twelve BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: You may need to loosen the SCREWS in the CORNER å...
  • Page 19 Step Step 14 Fasten the LIFT TABLE MECHANISMS (23M) to the TOP (E). å Use six BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: Be sure to position the LIFT TABLE MECHANISMS on å the TOP exactly as shown. BLACK 9/16" LARGE HEAD SCREW (6 used in this step) The holes are closer to this edge.
  • Page 20 Step Step 15 Fasten the SUPPORT BRACKETS (37G) to the LIFT å TABLE MECHANISMS (23M). Use four WASHERS (13M), NUTS (24M), and BLACK 3/4" MACHINE SCREWS (92S). NOTE: Be sure to position SUPPORT BRACKETS exactly å as shown. BLACK 3/4" MACHINE SCREW (4 used in this step) Page 20...
  • Page 21 Step Step 16 Carefully stand your unit upright. å IMPORTANT: You will need someone's help in this step. å NOTE: Be careful when lining up the holes in the MECHANISMS with the holes in the ENDS as to not damage any parts. å...
  • Page 22 Step Step 17 Finish fastening the TOP (E) to the UPPER ENDS (A and B). å Use two BUSHINGS (91M) and two BLACK 3/4" PAN HEAD Almost time to SCREWS (85S) through the exact holes shown in the LIFT celebrate! With a nap. TABLE MECHANISMS (23M) and into the holes in the ENDS.
  • Page 23 Step Step 18 IMPORTANT: Do not place valuables in the storage space. å Fasten the BRACE (J) to the SUPPORT BRACKETS (37G) on the LIFT TABLE MECHANISMS (23M). Use four å WASHERS (13M), NUTS (24M), and BLACK 1-1/4" MACHINE SCREWS (93S). NOTE: Do not place the BRACE (J) between the LIFT TABLE MECHANISMS (23M).
  • Page 24 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves. •...
