7.2 Charging the battery

1. Connect the provided charging adapter to the NEP-5000-LINK interface module and apply power.
2. At any time, you can monitor the charging status of the module by pressing on the NEP-5000-LINK
interface button. The LED indicator is flashing green, blue and red to indicate that the battery is
charging.
3. We highly recommend to use the application to monitor the battery level, please refer to chapter 8,
Section 8.13: "Read the Bluetooth battery level".
Note: The best way to verify if the battery is fully charged is to use the Android Application to monitor
the battery level. The user should expect that the charge will take up to three hours of charging from
fully flat battery.
4. When battery is fully charged, disconnect the charging cable and screw the protective cap back on.
