Feiss Mattix Series Installation Instructions

Installation Instructions for
Mattix ADA Outdoor Wall (LED)
Wall
G ENERAL RODUCT NFORMATION P
These fixtures are intended to be installed utilizing
junction boxes.
This product is safety listed for wet locations.
For a complete list of dimmers, visit out website at
1A
NEUTRAL WIRE
JUNCTION BOX
8
HOT
WIRE
MOUNTING PLATE
1 For Models OL11602, OL11603
For Models OL11602, OL11603
2
plate.
For Models OL11602, OL11603
3
Secure the mounting plate to the junction box.
4
For Models OL11602, OL11603
5
Connect the fixture to a suitable ground in accordance with local electrical codes.
6
7 Connect the white driver wire to the neutral power line wire with a wire nut.
8 Connect the black driver wire to the hot power line wire with a wire nut.
Mount the fixture base onto the mounting plate and secure it with the fixture screws.
9
For wet locations, caulk around the base of the fixture with waterproof construction sealant.
10
I :
NEC compliant
www.Feiss.com
4
WHITE WIRE
4
7
BLACK
4
WIRE
4
ANCHOR
ANCHOR
Only: Temporarily install the mounting plate to the junction box.
Only: Mark the anchor hole locations on the mounting plate and remove the mounting
Only: Drill appropriate size holes at the marked locations and install the anchors.
Only: Screw the anchor screws into the anchors.
O 11601, O 11602, O 11603-LED L
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
5
5
9
5
5
5
5
SCREW
9
1
OL11601_OL11602_O 11603-LED
L L
CAUTION RISK OF FIRE -
9
FIXTURE
FIXTURE SCREW
9
L
1.0
10
