Feiss OL13500 Installation Instructions

Installation Instructions for
Herald Outdoor Wall
Outdoor
G ENERAL RODUCT NFORMATION P
These fixtures are intended to be installed utilizing
boxes.
This product is safety listed for wet locations.
Incandescent lamps may be dimmed with a standard incandescent dimmer.
LED lamps may be dimmed with a
additional information.
This instruction shows a typical installation.
1A
ARM
ARM SCREW
JUNCTION BOX
4
5
6
MOUNTING
PLATE
FIXTURE
SCREW
10
1 Install the curved end of the arm to the fixture loop, then secure the other end of the arm to the top of the fixture base
using the arm screws.
Secure the mounting plate to the junction box.
2
Connect the fixture to a suitable ground in accordance with local electrical codes.
3
Connect the white fixture wire to the neutral power line wire with a wire nut.
4
Connect the black fixture wire to the hot power line wire with a wire nut.
5
Mount the fixture base onto the mounting plate and secure it with the fixture screws.
6
7 Insert the glass panels into the shade and secure them in place using the panel brackets and screws.
Screw the lamp into the socket. Refer to the label on the socket for Max Wattage Information.
8
Install the shade onto the fixture using the shade screws.
9
For wet locations, caulk around the base of the fixture with waterproof construction sealant.
10
I :
NEC compliant junction
LED dimmer. Consult lamp manufacturer for
FIXTURE
FIXTURE
BASE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
LOOP
PANEL SCREW
AND BRACKET
GLASS PANEL
1
O 13500
CAUTION RISK OF FIRE -
7
9 SHADE SCREW
SHADE
O 13500 L
L
1.0
FIXTURE
LAMP
