Feiss OL11113 Installation Instructions

Installation Instructions for
Pediment 3 Light Outdoor Flush Mount
Outdoor
G ENERAL RODUCT NFORMATION P
These fixtures are intended to be installed utilizing NEC compliant
junction boxes.
This product is safety listed for damp locations.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
1A
1 1
Secure the mounting plate to the junction box.
Install the glass panels by carefully inserting them into the frame and securing them using the tabs.
2
Connect the fixture to a suitable ground in accordance to local electrical codes.
3
Connect the white fixture wire to the neutral power line wire with a wire nut.
4
Connect the black fixture wire to the hot power line wire with a wire nut.
1 5
6 Place the fixture base onto the mounting plate studs and secure it in place by screwing the cap nuts onto the studs.
Screw the lamps into the sockets. Refer to the label on the lamp socket for Max Wattage information.
7
8 Place the shade onto the threaded pipe and secure it in place by screwing the hex nut onto the threaded pipe.
Screw the finial onto the threaded pipe.
9
I :
MOUNTING PLATE
CAP NUT
LAMP
7
THREADED PIPE
SHADE
HEX NUT
CAUTION - RISK OF FIRE
This product must be installed in accordance with the
applicable installation code by a person familiar with the
construction and operation of the product and the hazards
involved.
Use minimum 90°c supply conductors.
5 4
MOUNTING PLATE STUD
6 6
8
FINIAL
9
GLASS PANEL
1
O 11113 L
FIXTURE BASE
TAB
2
O 11113 L
1.1
