Feiss OL13507 Installation Instructions

Installation Instructions for
Herald Outdoor Post
Outdoor
G ENERAL RODUCT NFORMATION P
This product is safety listed for wet locations.
Incandescent lamps may be dimmed with a standard incandescent dimmer.
LED lamps may be dimmed with a
additional information.
This instruction shows a typical installation.
1A
LAMP
CANDLE
FOLLOWER
CANDLE
TUBE
4
POST SCREW
3
POST
Connect the fixture to a suitable ground in accordance to local electrical codes.
1
2 Connect the white fixture wire to the neutral power line wire with a wire nut.
Connect the black fixture wire to the hot power line wire with a wire nut.
3
Secure the fixture to the post with the post screws making sure to neatly tuck in all wiring.
4
5 Install the candle followers by placing them on top of the candle tubes.
Screw the lamp into the socket. Refer to the label on the socket for Max Wattage Information.
6
Insert the glass panels into the shade and secure them in place using the panel brackets and screws.
7
8
Install the fixture cover onto the fixture using the cover screws.
I :
LED dimmer. Consult lamp manufacturer for
6
5
FIXTURE
4
2
CAUTION RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
7
8
1
OL13507
-
FIXTURE COVER
PANEL SCREW
AND BRACKET
COVER SCREW
8
FIXTURE
OL13507
1.0
